Toyota Cresta

1996-09 → 2001-06 · chassis GX10#,JZX10#,LX100 · catalogue 313180 · Japan

Discontinued model Data version 1998-08
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Suspension Crossmember & Under Cover

17 part groups · 2 illustrations

Illustrations

Figure 510045B 510045B 1996-09 → — Figure 510046F 510046F 1996-09 → —

Part groups

PNCDescription
51201 Crossmember Sub-assy, Front Suspension
51202C Crossmember Sub-assy, Front Suspension, Lower
51206A Member Sub-assy, Rear Suspension
51229C Plate, Suspension Member Set
51249 Damper, Rear Suspension Member
51441 Cover, Engine Under, NO.1
51447B Protector, Oil Pan
51454C Silencer, Engine Under Cover, Rear
51967 Hook, Transport, Rear
52205H Cushion Sub-assy, Body Mounting, Rear RH
52206C Cushion Sub-assy, Body Mounting, Rear LH
52271D Cushion, Rear Suspension Member Body Mounting, Front
52273A Stopper, Rear Suspension Member, Lower RH
52274A Stopper, Rear Suspension Member, Lower LH
52285 Bolt, Differential Support Member Mounting, NO.1
52295 Brace, Rear Suspension Member, RH
52296 Brace, Rear Suspension Member, LH
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
