Toyota Soarer
1991-05 → 2000-12 · chassis JZZ3#,UZZ3# · catalogue 321140 · Japan
Discontinued model
Data version 2001-07
Traction Control
9 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 84988 | Switch, Traction Control |
| 84988A | Bulb, Traction Control Switch |
| 86650J | Buzzer Assy |
| 88278 | Cushion, Skid Control Computer |
| 89452C | Sensor, Throttle Position |
| 89631 | Computer, Traction Control |
| 89632 | Motor, Traction Throttle Valve |
| 89633 | Relay, Traction Control |
| 89634 | Bracket, Traction Control Computer |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
