Toyota Soarer
1991-05 → 2000-12 · chassis JZZ3#,UZZ3# · catalogue 321140 · Japan
Discontinued model
Data version 2001-07
Navigation & Front Monitor Display
30 part groups · 8 illustrations
Part groups
| PNC | Description |
|---|---|
| 04861 | Disk Kit, Disc Player |
| 86010 | Tuner Assy, Television |
| 86017A | Parts Set, Video |
| 86050B | Antenna Assy, Television |
| 86050C | Antenna Assy, Television |
| 86101H | Cord Sub-assy, Antenna |
| 86102A | Selector Sub-assy, Antenna |
| 86111 | Multi-display |
| 86112 | Computer, Multi-display (COMPUTER CRT DISPLAY) |
| 86114 | Computer, Audio Interface |
| 86129 | Filter, Multi-display |
| 86191 | Terminal, Video(VIDEO ADAPTER) |
| 86271 | Disc, Disc Player |
| 86273A | Magazine, Disc Player |
| 86274D | Bracket, Disc Player |
| 86274F | Bracket, Disc Player, NO.2 |
| 86274G | Bracket, Disc Player, NO.3 |
| 86808 | Cord Sub-assy, Navigation Antenna, NO.1 |
| 86808A | Cord Sub-assy, Navigation Antenna, NO.2 |
| 86841 | Computer, Navigation |
| 86851 | Receiver, Navigation |
| 86860 | Antenna Assy, Navigation |
| 86860A | Antenna, Navigation |
| 86870 | Player Assy, Cd-rom |
| 86900 | Computer Assy, Traffic Information |
| 86914 | Receiver, Radio Beacon |
| 86915 | Transceiver, Optical Beacon |
| 86916 | Separator, Traffic Information FM |
| 86920 | Antenna Assy, Traffic Information |
| 86931 | Computer, Traffic Information |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
