Caution Plate (EXTERIOR & INTERIOR)

13 part groups · 2 illustrations

Illustrations

Figure 740889D 740889D 2001-04 → — Figure 741486C 741486C 2001-04 → —

Part groups

PNCDescription
11296C Label, Engine Service Information
63297E Label, Sliding Roof Caution
74511F Label, Name (IDENTIFICATION LASER LABEL)
74515A Plate, Theft Warning
74533E Label, Headlamp Voltage Caution
74541E Plate, Compact Spare Tire Caution
74562B Label, Emission Information
74579A Label, Unleaded Fuel Information
74751 Label, Tire Pressure Information
87511A Plate, Seat Heater Caution
87529B Label, A/C Filter Information
88723E Label, Cooler Service Caution
89176A Label, Airbag Deployment Information
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
