Toyota Progres

1998-05 → 2007-06 · chassis JCG1# · catalogue 322110 · Japan

Discontinued model Data version 2008-01

Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Heating & Air Conditioning - Water Piping

8 part groups · 2 illustrations

Illustrations

Figure 872688D

872688D 1998-05 → —

Figure 874723D

874723D 1998-05 → —

Part groups

PNC	Description
87019C	Grommet, Heater Hose
87245A	Hose, Heater Water, Inlet A
87245B	Hose, Heater Water, Inlet B
87245X	Hose, Heater Water
87246A	Hose, Heater Water, Outlet A
87246B	Hose, Heater Water, Outlet B
87246X	Hose, Heater Water
87248	Pipe Sub-assy, Water

PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
