Toyota Brevis

2001-05 → 2007-06 · chassis JCG1# · catalogue 324110 · Japan

Discontinued model Data version 2008-01
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Suspension Crossmember & Under Cover

19 part groups · 2 illustrations

Illustrations

Figure 510400K 510400K 2001-05 → — Figure 510560C 510560C 2001-10 → —

Part groups

PNCDescription
51201 Crossmember Sub-assy, Front Suspension
51202C Crossmember Sub-assy, Front Suspension, Lower
51206A Member Sub-assy, Rear Suspension
51229C Plate, Suspension Member Set
51403A Brace Sub-assy, Front Suspension Member, RH
51441D Cover, Engine Under
51442E Cover, Engine Under, NO.2
51443C Cover, Engine Under, Rear RH
51444A Cover, Engine Under, Rear LH
51967 Hook, Transport, Rear
52271D Cushion, Rear Suspension Member Body Mounting, Front
52273 Stopper, Rear Suspension Member, Lower
52275A Cushion, Rear Suspension Member Body Mounting, Rear
52277B Stopper, Rear Suspension Member, Rear Upper
52278C Stopper, Rear Suspension Member, Rear Lower
52283B Stopper, Differential Support Member, Lower
52285 Bolt, Differential Support Member Mounting, NO.1
52286 Bolt, Differential Support Member Mounting, NO.2
52295 Brace, Rear Suspension Member, RH
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
