Toyota Crown
1979-09 → 1983-07 · chassis GS11#,LS11#,MS11#,RS110 · catalogue 331140 · Japan
Discontinued model
Data version 1984-02
Switch & Relay & Computer
133 part groups · 13 illustrations
Illustrations
Part groups
| PNC | Description |
|---|---|
| 27659 | Resistor, Solenoid |
| 27700 | Regulator Assy, Generator |
| 27751 | Bracket, Generator Regulator |
| 27790 | Relay Assy, Charge Lamp |
| 28300 | Relay Assy, Starter |
| 28301 | Relay Assy, Fuel Pump |
| 28515A | Resistor, Solenoid |
| 28521 | Timer, Preheating |
| 28529 | Bracket, Preheating Timer, NO.1 |
| 28560A | Block, Heater |
| 28610 | Relay Assy, Intake Heater OR Glow Plug |
| 28611 | Cover, Glow Plug Relay |
| 28621 | Resistor, Glow Plug |
| 28631 | Sensor, Glow Plug Current |
| 81944 | Cord, Optical Fiber |
| 81980 | Flasher Assy, Turn Signal |
| 82600F | Fuse, Fuse Block |
| 82602 | Block Sub-assy, Relay |
| 82650 | Breaker Assy, Wiring Circuit, NO.1 |
| 82661 | Cover, Relay Block, NO.1 |
| 83301 | Gage Sub-assy, Fuel Sender (FOR LPG TANK) |
| 83302 | Body Sub-assy, Fuel Sender Gage |
| 83320 | Gage Assy, Fuel Sender |
| 83361 | Gasket, Fuel Sender Gage |
| 83380 | Switch Assy, Presure |
| 83390 | Switch Assy, Vacuum Warning |
| 83391 | Switch, Vacuum |
| 83399 | Bracket, Vacuum Switch |
| 83420 | Gage Assy, Water Temperature Sender |
| 83530 | Switch Assy, Oil Pressure (FOR ENGINE) |
| 83650 | Fusee |
| 83651 | Clamp, Fusee |
| 84095 | Bracket Sub-assy, Hand Brake Signal Switch |
| 84110 | Switch Assy, Light Control, NO.1 |
| 84118 | Knob, Light Control Rheostat |
| 84119 | Rheostat, Light Control |
| 84140 | Switch Assy, Headlamp Dimmer |
| 84162 | Switch, Front Fog Lamp |
| 84210 | Switch Assy, Back-up Lamp |
| 84210T | Sensor Assy, Shift Point |
| 84230 | Switch Assy, Courtesy Lamp (FOR ENGINE ROOM) |
| 84230A | Bracket, Engine Room Courtesy Switch |
| 84231 | Switch Assy, Courtesy Lamp (FOR PARKING BRAKE) |
| 84232 | Switch Assy, Courtesy Lamp (FOR GLOVE BOX) |
| 84233 | Switch Assy, Courtesy Lamp (FOR FRONT DOOR) |
| 84234 | Switch Assy, Courtesy Lamp (FOR REAR DOOR) |
| 84235 | Switch Assy, Courtesy Lamp(FOR BACK DOOR) |
| 84236 | Switch Assy, Courtesy Lamp(FOR LUGGAGE COMPARTMENT ROOM) |
| 84236A | Bracket, Courtesy Switch(FOR LUGGAGE COMPARTMENT ROOM) |
| 84285 | Switch, Map Lamp |
| 84285A | Bolt OR Nut, Map Lamp Switch |
| 84310 | Switch Assy, Turn Signal |
| 84312 | Plate, Horn Contact |
| 84330 | Switch Assy, Hazard Warning Signal |
| 84335 | Switch Assy, Parking Lamp |
| 84340 | Switch Assy, Stop Lamp |
| 84380 | Switch Assy, Brake Warning Test |
| 84450 | Switch Assy, Ignition OR Starter |
| 84461 | Switch, Level Warning |
| 84532 | Switch, Room Lamp Retainer |
| 84540 | Switch Assy, Neutral Start |
| 84550 | Switch Assy, Parking Brake |
| 84560 | Switch Assy, Fuel Valve Control |
| 84650 | Switch Assy, Windshield Wiper |
| 84653A | Switch, Rear Wiper |
| 84720A | Switch Assy, Pattern Select, NO.1 |
| 84730 | Switch Assy, Heater Blower |
| 84731 | Knob, Heater Blower Switch |
| 84751 | Switch, Seat Heater |
| 84751A | Knob, Seat Heater Switch |
| 84763 | Plate, Switch |
| 84790 | Switch Assy, Rear Window Defogger |
| 84810 | Switch Assy, Power Window Regulator |
| 84820 | Master Switch Assy, Power Window Regulator |
| 84840 | Switch Assy, Luggage Compartment Door Opening |
| 84870A | Switch Assy, Outer Mirror |
| 84920 | Switch Assy, Power Seat |
| 84921 | Knob, Power Seat Switch |
| 84930 | Switch Assy, Door Control |
| 85410 | Solenoid Assy, Luggage Door Lock |
| 85450 | Solenoid Assy, Door Control, Front RH |
| 85460 | Solenoid Assy, Door Control, Front LH |
| 85460A | Solenoid Assy, Lap Belt |
| 85470 | Solenoid Assy, Door Control, Rear RH |
| 85480 | Solenoid Assy, Door Control, Rear LH |
| 85490 | Solenoid Assy, Door Control Back |
| 85500 | Lighter Assy, Cigarette |
| 85533 | Lens, Cigarette Lighter Indicator |
| 85820 | Motor Assy, Power Seat (FOR REAR) |
| 85820A | Motor Assy, Power Seat (FOR FRONT UP, DOWN) |
| 85820B | Motor Assy, Power Seat (FOR FRONT SLIDE) |
| 85910C | Relay Assy (FOR HEATER BLOWER MOTOR) |
| 85910D | Relay (FOR HEATER IDLE UP) |
| 85910E | Relay, Injector |
| 85915 | Relay, Main |
| 85916 | Relay, Light Control |
| 85916C | Relay, Back UP Lamp |
| 85916D | Relay, Fog Lamp |
| 85919 | Relay, Solenoid Lock Door Control |
| 85923 | Relay, Choke Control |
| 85930 | Relay Assy, Power Window |
| 85931 | Relay, Emission Control |
| 85939 | Relay, Power Window |
| 85940 | Relay Assy, Windshield Wiper |
| 85961 | Relay, Headlamp Retainer |
| 85965 | Relay, Room Lamp Control |
| 85980 | Relay Assy, Door Control |
| 85999 | Bracket, Combination Relay |
| 85999A | Bracket, Relay, NO.2 |
| 85999C | Bracket, Relay, NO.3 |
| 85999D | Bracket, Relay, NO.4 |
| 85999E | Bracket, Relay, NO.5 |
| 86690 | Buzzer Assy, Speed Indicator |
| 87510 | Heater Assy, Seat |
| 89371 | Relay, Lamp Failure Indicator |
| 89373 | Sensor, Lamp Failure Indicator |
| 89425 | Sensor, Exhaust Gas Temperature |
| 89427 | Switch, Temperature Detect |
| 89428 | Switch, Temperature Detect, NO.2 |
| 89429 | Sensor, Oil Temperature |
| 89437 | Cover, Sensor |
| 89453 | Switch, Throttle Position (FOR T.C.S.) |
| 89465 | Sensor, Oxygen |
| 89466 | Gasket, Oxygen Sensor |
| 89550 | Computer Assy, Emission Control |
| 89559 | Bracket, Emission Control Computer |
| 89610 | Computer Assy, Knock Control |
| 89615 | Sensor, Knock Control |
| 89620 | Igniter Assy |
| 89641 | Sensor, Magnetic Field |
| 89650 | Computer Assy, Power Steering |
| 89710 | Computer Assy, Position Control |
| 89711 | Sensor, Position Control |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
