Toyota Crown
1983-08 → 1987-08 · chassis GS12#,LS12#,MS12#,YS120 · catalogue 331150 · Japan
Discontinued model
Data version 1988-01
Frame
37 part groups · 3 illustrations
Part groups
| PNC | Description |
|---|---|
| 51011 | Rail Sub-assy, Front Frame |
| 51012 | Rail Sub-assy, Rear Frame |
| 51105 | Rail Sub-assy, Center Frame, RH |
| 51106 | Rail Sub-assy, Center Frame, LH |
| 51203C | Crossmember Sub-assy, Center Bearing Support |
| 51204C | Damper Sub-assy, Engine Rear Support Member |
| 51205B | Support Sub-assy, Strut Bar, RH |
| 51207A | Member Sub-assy, Differential Support |
| 51208B | Support Sub-assy, Strut Bar, LH |
| 51243 | Member, Anti Shake |
| 51266 | Gusset, Frame Crossmember, RH |
| 51267 | Gusset, Frame Crossmember, LH |
| 51291 | Crossmember, Frame, Rear |
| 51301A | Bracket Sub-assy, Rear Spring, Rear RH |
| 51302A | Bracket Sub-assy, Rear Spring, Rear LH |
| 51313 | Gusset, Front Frame, Lower RH |
| 51314 | Gusset, Front Frame, Lower LH |
| 51381 | Bracket, Jack UP Front, RH |
| 51382 | Bracket, Jack UP Front, LH |
| 51441 | Cover, Engine Under, NO.1 |
| 51443 | Cover, Engine Under, Rear RH |
| 51444 | Cover, Engine Under, Rear LH |
| 51448A | Cover, Engine Side Under, RH |
| 51449A | Cover, Engine Side Under, LH |
| 51450 | Cover Assy, Engine Under, Rear |
| 51621 | Bracket, Rear Bound Stopper, RH |
| 51622 | Bracket, Rear Bound Stopper, LH |
| 51961 | Hook, NO.1 |
| 52281A | Cushion, Differential Support Member |
| 52282A | Stopper, Differential Support Member, Upper |
| 52283A | Stopper, Differential Support Member, Lower |
| 52291A | Cushion, Differential Support Member, Rear |
| 57209 | Member Sub-assy, Engine Rear Support |
| 57774 | Bracket, Rear Frame Rear Body Mounting, NO.7 RH |
| 57775 | Bracket, Rear Frame Rear Body Mounting, NO.7 LH |
| 57776 | Bracket, Rear Frame Rear Body Mounting, NO.8 RH |
| 57777 | Bracket, Rear Frame Rear Body Mounting, NO.8 LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
