Toyota Crown
1987-09 → 1991-10 · chassis GS13#,LS13#,MS13#,YS130,UZS131,JZS13# · catalogue 331160 · Japan
Discontinued model
Data version 1992-04
Lpg Carburetor
43 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 21548A | Coller, Throttle Lever |
| 21908D | Actuator Sub-assy, Idle-up |
| 26200 | Carburetor Assy, Lpg |
| 26200A | Insulator, Lpg Carburetor Heat |
| 26200E | Gasket, Carburetor, NO.1 |
| 26200F | Gasket, Carburetor, NO.2 |
| 26200G | Spring, Tension W/Damper |
| 26200H | Gasket, Carburetor, NO.2 |
| 26203 | Valve Sub-assy, Solenoid, NO.2 |
| 26204A | Valve, Throttle Solenoid(FOR LPG) |
| 26204B | Gasket, Solenoid Valve(FOR LPG) |
| 26204H | Spring, Throttle Return(FOR LPG) |
| 26206R | Screw, Throttle Adjust(FOR LPG) |
| 26206S | Spring, Idle Adjust Screw(FOR LPG) |
| 26208 | Valve Sub-assy, Solenoid |
| 26209 | Diaphragm Sub-assy(FOR LPG) |
| 26213 | Screw, Adjust |
| 26214 | Screw, Power Adjust |
| 26215 | Nut, Power Adjust |
| 26216 | Valve, Power |
| 26218 | Boot(FOR POWER VALVE) |
| 26219 | Spring, Power Valve |
| 26223 | Screw, Set(FOR POWER VALVE CAM) |
| 26231 | Screw(FOR LPG CARBURETOR) |
| 26233 | Stay, Stud |
| 26236 | Gasket, Air Horn |
| 26239 | Spring |
| 26244 | Collar(FOR LPG CARBURETOR) |
| 26246 | Jet |
| 26247 | Diaphragm |
| 26248 | Spring(FOR POWER VALVE CAM) |
| 26249 | Union, Fuel Hose(FOR LPG) |
| 26251 | Horn, Air |
| 26252 | Valve, Thermostatic |
| 26252A | Hose, Connecting |
| 26252B | Gasket, NO.1(FOR THERMOSTATIC VALVE) |
| 26252C | Gasket, NO.2(FOR THERMOSTATIC VALVE) |
| 26253 | Valve, Change(FOR SLOW) |
| 26254 | Cap, Power Screw Limit |
| 26256 | Gasket, Change Valve |
| 26262 | Cover |
| 26266 | Gasket, Fuel Inlet Union |
| 26280 | Motor Assy, Air Fuel Ratio Control |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
