Toyota Crown
1987-09 → 1991-10 · chassis GS13#,LS13#,MS13#,YS130,UZS131,JZS13# · catalogue 331160 · Japan
Discontinued model
Data version 1992-04
Camera & Rear Monitor Display
15 part groups · 7 illustrations
Part groups
| PNC | Description |
|---|---|
| 82817Q | Protector, Wiring Harness, NO.15 |
| 86010A | Tuner Assy, Television |
| 86011J | Filter, Noise |
| 86117A | Bracket, Television Display, A |
| 86118A | Bracket, Television Display, B |
| 86119A | Wire, Television Switch |
| 86170B | Switch & Volume Assy, Television |
| 86191A | Terminal, Video(VIDEO ADAPTER) |
| 86291 | Bracket, Television |
| 86292 | Cover, Television Set |
| 86680A | Display Assy, Television |
| 86681 | Divider, Antenna |
| 86685 | Light, Television |
| 86686 | Plug, Television NO.1 |
| 86687 | Plug, Television NO.2 |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
