Toyota Crown/Crown Majesta
1991-10 → 1995-08 · chassis JZS14#,LS141,UZS14#,GS141 · catalogue 331180 · Japan
Discontinued model
Data version 1996-03
Switch & Relay & Computer
143 part groups · 19 illustrations
Illustrations
Part groups
| PNC | Description |
|---|---|
| 28300 | Relay Assy, Starter |
| 28610 | Relay Assy, Intake Heater OR Glow Plug |
| 28610A | Relay Assy, Glow Plug(SUB) |
| 28621 | Resistor, Glow Plug |
| 55905G | Knob Sub-assy, Control |
| 81980 | Flasher Assy, Turn Signal |
| 82285A | Wire, Illumination |
| 82600F | Fuse, Fuse Block |
| 82600M | Fuse, Medium Current |
| 82616 | Puller, Fuse |
| 82641 | Relay, Integration NO.1 |
| 82650 | Breaker Assy, Wiring Circuit, NO.1 |
| 82660C | Block Assy, Relay |
| 82661 | Cover, Relay Block, NO.1 |
| 82666 | Holder, Connector |
| 82670A | Block Assy, Junction, NO.1 |
| 82671D | Block, Junction |
| 82671E | Block, Junction |
| 82671G | Block, Junction |
| 82815 | Cover, Wiring Harness Protector |
| 82825A | Cover, Relay |
| 83320 | Gage Assy, Fuel Sender |
| 83361 | Gasket, Fuel Sender Gage |
| 83380A | Switch Assy, Pressure |
| 83390 | Switch Assy, Vacuum Warning |
| 83420 | Gage Assy, Water Temperature Sender |
| 83530 | Switch Assy, Oil Pressure (FOR ENGINE) |
| 83650 | Fusee |
| 84110 | Switch Assy, Light Control, NO.1 |
| 84119 | Rheostat, Light Control |
| 84140 | Switch Assy, Headlamp Dimmer |
| 84220D | Switch Assy, Brake Differential Valve |
| 84231A | Switch, Courtesy Lamp |
| 84236 | Switch Assy, Courtesy Lamp(FOR LUGGAGE COMPARTMENT ROOM) |
| 84242 | Switch, Glove Box Lamp |
| 84290 | Switch Assy, Limit |
| 84306 | Cable Sub-assy, Spiral |
| 84310 | Switch Assy, Turn Signal |
| 84312 | Plate, Horn Contact |
| 84315 | Slipring, Horn Contact |
| 84317 | Sensor, Steering Position |
| 84329 | Switch, Turn Signal |
| 84330 | Switch Assy, Hazard Warning Signal |
| 84330B | Bulb, Hazard Warning Signal Switch |
| 84330D | Cap, Hazard Warning Switch Bulb |
| 84340 | Switch Assy, Stop Lamp |
| 84450 | Switch Assy, Ignition OR Starter |
| 84461 | Switch, Level Warning |
| 84540 | Switch Assy, Neutral Start |
| 84550 | Switch Assy, Parking Brake |
| 84553 | Cover, Parking Brake Switch |
| 84650 | Switch Assy, Windshield Wiper |
| 84727 | Switch, Shift Lock Control |
| 84742 | Switch, Slide Roof Limit |
| 84751 | Switch, Seat Heater |
| 84751B | Bulb, Seat Heater Switch |
| 84810 | Switch Assy, Power Window Regulator |
| 84810D | Switch Assy, Power Window Regulator, Rear |
| 84820 | Master Switch Assy, Power Window Regulator |
| 84840 | Switch Assy, Luggage Compartment Door Opening |
| 84841A | Switch, Fuel Lid Opener |
| 84870A | Switch Assy, Outer Mirror |
| 84903 | Switch Sub-assy, Door Un-lock |
| 84920C | Switch Assy, Power Seat Front, RH |
| 84920D | Switch Assy, Power Seat Front, LH |
| 84920E | Switch Assy, Power Seat Front Headrest |
| 84921C | Knob, Power Seat Switch, RH |
| 84921D | Knob, Power Seat Switch, LH |
| 84922B | Switch, Front Power Seat, RH |
| 84922C | Switch, Front Power Seat, LH |
| 84923 | Switch, Rear Power Seat |
| 84923B | Bulb(FOR REAR POWER SEAT SWITCH) |
| 84923C | Switch, Rear Power Seat Return |
| 84923D | Cap(FOR REAR POWER SEAT SWITCH) |
| 84926 | Switch, Height Adjustable Anchor |
| 84927 | Switch, Seat Memory |
| 85431 | Solenoid, Shift Lock |
| 85432 | Solenoid, Key Interlock |
| 85500 | Lighter Assy, Cigarette |
| 85500B | Bulb, Cigarette Lighter |
| 85500F | Cap, Cigarette Lighter Bulb |
| 85500G | Lighter Assy, Cigarette, Rear |
| 85500H | Cap, Cigarette Lighter Bulb, Rear |
| 85500J | Bulb, Cigarette Lighter, Rear |
| 85513A | Cover, Cigarette Lighter, Rear |
| 85515 | Stay, Cigarette Lighter Bezel |
| 85533 | Lens, Cigarette Lighter Indicator |
| 85533A | Lens, Cigarette Lighter Indicator, Rear |
| 85870A | Computer Assy, Vibration Seat |
| 85880 | Relay Assy, Power Seat |
| 85900 | Relay Assy, Control Unit |
| 85910C | Relay Assy (FOR HEATER BLOWER MOTOR) |
| 85912 | Relay, Defogger |
| 85915 | Relay, Main |
| 85916D | Relay, Fog Lamp |
| 85916F | Relay, Cornering Lamp |
| 85916N | Relay, Taillamp |
| 85916P | Relay, Headlamp |
| 85921 | Relay, Sliding Roof Control |
| 85927 | Relay, Cooling Fan |
| 85930 | Relay Assy, Power Window |
| 85931B | Relay, Fuel Heater |
| 85933 | Computer, Shift Lock Control |
| 85940 | Relay Assy, Windshield Wiper |
| 85961 | Relay, Headlamp Retainer |
| 85980 | Relay Assy, Door Control |
| 85985 | Relay, Key Reminder |
| 85999C | Bracket, Relay, NO.3 |
| 85999D | Bracket, Relay, NO.4 |
| 85999R | Bracket, Relay, NO.6 |
| 86530 | Relay Assy, Horn |
| 87989 | Relay, Mirror Control |
| 88291A | Bracket, Speed Control, A |
| 88630G | Relay Assy, Cooler |
| 89090 | Computer Assy, Multiplex Manager |
| 89140 | Computer,Assy Mirror Viblation Control |
| 89230 | Computer Assy, Tilt Steering |
| 89233 | Sensor, Tilt Position |
| 89235 | Switch, Tilt Steering |
| 89237 | Bracket, Computer Unit |
| 89257 | Computer, Cooling Fan |
| 89293E | Relay, Air Suspension |
| 89371 | Relay, Lamp Failure Indicator |
| 89373 | Sensor, Lamp Failure Indicator |
| 89390 | Relay, Brake Warning |
| 89422A | Sensor, Water Temperature |
| 89425 | Sensor, Exhaust Gas Temperature |
| 89427 | Switch, Temperature Detect |
| 89428 | Switch, Temperature Detect, NO.2 |
| 89430 | Computer Assy, Outer Mirror Control |
| 89438 | Switch, Power Steering Oil Pressure |
| 89439 | Bracket, Sensor |
| 89465 | Sensor, Oxygen |
| 89466 | Gasket, Oxygen Sensor |
| 89491 | Sensor, Engine Oil Level |
| 89615 | Sensor, Knock Control |
| 89620 | Igniter Assy |
| 89629 | Bracket, Igniter Assy |
| 89634A | Bracket, Multiplex Manager Computer |
| 89641 | Sensor, Magnetic Field |
| 89650 | Computer Assy, Power Steering |
| 89710 | Computer Assy, Position Control |
| 89711 | Sensor, Position Control |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
