Toyota Crown/Crown Majesta
1995-08 → 2001-08 · chassis GS151,JZS15#,LS151,UZS15# · catalogue 331190 · Japan
Discontinued model
Data version 2003-10
Roof Panel & Back Window Glass
52 part groups · 6 illustrations
Part groups
| PNC | Description |
|---|---|
| 04641 | Dam Kit, Back Window Glass |
| 56115B | Stopper, Back Window Glass, NO.1 |
| 63102A | Panel Sub-assy, Windshield Header |
| 63103A | Reinforcement Sub-assy, Roof Panel |
| 63105D | Frame Sub-assy, Back Window, Upper |
| 63111 | Panel, Roof |
| 63118 | Support, Roof Panel, RH |
| 63133A | Frame, Back Window, Upper |
| 63141H | Reinforcement, Roof Panel, Center |
| 63143B | Reinforcement, Roof Panel, NO.3 |
| 63144A | Reinforcement, Roof Panel, NO.4 |
| 63148A | Reinforcement, Roof Panel, NO.7 |
| 63149E | Bracket, Roof Panel Reinforcement, NO.2 |
| 63201G | Glass Sub-assy, Sliding Roof |
| 63203F | Housing Sub-assy, Sliding Roof |
| 63209 | Panel Sub-assy, Roof Wind Deflector |
| 63214F | Channel, Roof Drip, Rear |
| 63217G | Garnish, Sliding Roof Side, RH |
| 63218G | Garnish, Sliding Roof Side, LH |
| 63219A | Garnish, Sliding Roof, Rear |
| 63221 | Casing, Sliding Roof Cable Guide |
| 63223A | Cable, Sliding Roof Drive, RH |
| 63224A | Cable, Sliding Roof Drive, LH |
| 63233C | Panel, Sliding Roof Housing |
| 63235D | Frame, Sliding Roof Housing, Center |
| 63241B | Bracket, Sliding Roof Housing, NO.1 |
| 63245C | Bracket, Removable Roof, NO.1 |
| 63247 | Hose, Sliding Roof Housing Drain |
| 63249E | Hose, Sliding Roof Drain |
| 63260A | Gear Sub-assy, Sliding Roof Drive |
| 63265B | Gear, Sliding Roof Drive |
| 63603 | Rail Sub-assy, Sliding Roof Drive, RH |
| 63604A | Rail Sub-assy, Sliding Roof Drive, LH |
| 63625 | Block, Sliding Roof Guide, RH |
| 63626 | Block, Sliding Roof Guide, LH |
| 63635A | Garnish, Sliding Roof, Front |
| 63669B | Grommet, Sliding Roof Drain |
| 64101 | Panel Sub-assy, Upper Back |
| 64165B | Cover, Upper Back Panel Hole, NO.1 |
| 64167B | Cover, Upper Back Panel Hole, NO.3 |
| 64211A | Strainer, Package Tray TO Floor, RH |
| 64212A | Strainer, Package Tray TO Floor, LH |
| 64213A | Extension, Package Tray Strainer, RH |
| 64214A | Extension, Package Tray Strainer, LH |
| 64227B | Extension, Center Floor TO Blace, NO.1 |
| 64228B | Extension, Center Floor TO Brace, NO.2 |
| 64241D | Panel, Room Partition |
| 64312B | Bracket, Package Tray, RH |
| 64313B | Bracket, Package Tray, LH |
| 64314D | Extension, Package Tray Bracket, RH |
| 64315D | Extension, Package Tray Bracket, LH |
| 64811 | Glass, Back Window |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
