Toyota Crown/Crown Majesta
1999-09 → 2007-06 · chassis GS171,JKS175,JZS17#,UZS17# · catalogue 3311A0 · Japan
Discontinued model
Data version 2008-01
Shift Lever & Retainer
59 part groups · 3 illustrations
Part groups
| PNC | Description |
|---|---|
| 33281F | Pin, Lever Lock (FOR FLOOR SHIFT) |
| 33282D | Pin, Lever Lock, NO.2 |
| 33502 | Plate Sub-assy, Shift Lever |
| 33503F | Lever Sub-assy, Shift(FOR FLOOR SHIFT) |
| 33504C | Screw (FOR SHIFT LEVER KNOB SETTING) |
| 33504F | Knob Sub-assy, Shift Lever |
| 33511 | Shaft, Control (FOR FLOOR SHIFT) |
| 33511B | Bush (FOR CONTROL SHAFT) |
| 33523B | Pin, Shift Lever (FOR FLOOR SHIFT) |
| 33539 | Cushion, Shift Lever Anti-rattle |
| 33544 | Insert, Shift Lever, NO.1 |
| 33550D | Bulb, Position Indicator Lamp |
| 33550E | Cap, Position Indicator Lamp |
| 33554 | Cap, Shift Lever |
| 33555 | Boot, Shift Lever |
| 33559A | Nut, Shift Lever, NO.1 |
| 33560 | Unit Assy, Shift Lock Control |
| 33563 | Button, Shift Lock Release |
| 33564 | Link, Shift Lock Release, NO.1 |
| 33582B | Stopper, Shift Lock Plate (FOR FLOOR SHIFT) |
| 33589 | Link, Shift Lock Solenoid |
| 33589A | Spring, Compression (FOR SHIFT LOCK SOLENOID LINK) |
| 33589B | Pin, Slotted Spring (FOR SHIFT LOCK SOLENOID LINK) |
| 33598D | Spring, Compression(FOR LEVER LOCK PIN) |
| 33622 | Cover, Shift Lever Knob, NO.1 |
| 33623 | Button, Shift Lever Knob |
| 33623A | Spring, Compression (FOR SHIFT LEVER KNOB BUTTON) |
| 33625 | Sleeve, Shift Lever Knob |
| 33631 | Rod, Detent |
| 33631A | Spring, Compression (FOR DETENT ROD) |
| 33631D | Pin, Grooved (FOR DETENT ROD) |
| 33632 | Rod, Detent, NO.2 |
| 33635A | Guide, Wire, NO.1 (FOR SHIFT LEVER) |
| 33661 | Housing, Shift Lever Guide |
| 33663 | Lever, Control |
| 33675A | Pin, W/Hole (FOR TRANSMISSION CONTROL ROD) |
| 33675B | Bush (FOR TRANSMISSION CONTROL ROD) |
| 33675C | Grommet (FOR TRANSMISSION CONTROL ROD) |
| 33702B | Rod Sub-assy, Gear Shifting, NO.1 (FOR FLOOR SHIFT) |
| 33711F | Lever, Control Shaft (FOR FLOOR SHIFT) |
| 33723F | Swivel, Connecting Rod (FOR FLOOR SHIFT) |
| 33723G | Bush (FOR FLOOR SHIFT CONTROL SHAFT) |
| 33723S | Bush (FOR CONNECTING ROD SWIVEL) |
| 33851 | Plate, Shift Lock Switch |
| 33851A | Roller (FOR SHIFT LOCK SWITCH) |
| 33866 | Spring, Shift Lock Release |
| 33893 | Cap, Shift Lock Plate Stopper |
| 35198A | Bracket, Wire Harness Clamp, NO.4 |
| 35469L | Spacer, Shift Lever |
| 35906 | Wire Sub-assy, Indicator Lamp |
| 35906A | Housing, Connector Male (FOR INDICATOR LAMP WIRE) |
| 35921 | Plate, Control Position Indicator |
| 35952 | Lens, Position Indicator |
| 35953 | Guide, Position Indicator Light |
| 35971A | Housing, Position Indicator, Upper |
| 35974 | Housing, Position Indicator, Lower |
| 35975 | Cover, Slide (FOR POSITION INDICATOR) |
| 35976 | Cover, Slide, NO.2 (FOR POSITION INDICATOR) |
| 36385A | Spring, Floor Shift Lever Torsion, NO.1 |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
