Toyota Crown/Crown Majesta
1999-09 → 2007-06 · chassis GS171,JKS175,JZS17#,UZS17# · catalogue 3311A0 · Japan
Discontinued model
Data version 2008-01
Meter
28 part groups · 8 illustrations
Part groups
| PNC | Description |
|---|---|
| 83100B | Bulb, Combination Meter, NO.1 |
| 83101 | Socket Sub-assy, Combination Meter Bulb |
| 83119 | Bulb, Combination Meter, NO.3 |
| 83129C | Wire, Combination Meter |
| 83132 | Case, Combination Meter |
| 83133 | Plate, Combination Meter, NO.1 |
| 83133A | Plate, Combination Meter, NO.2 |
| 83133B | Plate, Combination Meter, NO.3 |
| 83134 | Cover, Combination Meter, NO.1 |
| 83134B | Cover, Combination Meter, NO.2 |
| 83138G | Glass, Combination Meter |
| 83141A | Computer, Combination Meter Mirror |
| 83142A | Wire, Combination Meter |
| 83144A | Mirror, Combination Meter |
| 83161 | Case, Combination Meter Mirror, NO.1 |
| 83162 | Case, Combination Meter Mirror, NO.2 |
| 83163 | Plate, Combination Meter Mirror, NO.1 |
| 83166 | Bracket, Combination Meter Mirror, NO.1 |
| 83166A | Bracket, Combination Meter Mirror, NO.1 |
| 83167 | Glass, Combination Meter Mirror |
| 83168 | Display, Combination |
| 83247 | Plate, Meter Circuit |
| 83247B | Plate, Meter Circuit, NO.2 |
| 83291 | Computer, Combination Meter |
| 83875 | Wire, Combination Meter, NO.1 |
| 83910 | Clock Assy |
| 83910B | Bulb, Clock Indicator |
| 86111C | Display, Multi-display (COMBINATION METER) |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
