Toyota Crown/Crown Majesta
1999-09 → 2007-06 · chassis GS171,JKS175,JZS17#,UZS17# · catalogue 3311A0 · Japan
Discontinued model
Data version 2008-01
Antenna
8 part groups · 3 illustrations
Part groups
| PNC | Description |
|---|---|
| 82046E | Wire Sub-assy, Body Ground |
| 86011M | Filter, Noise |
| 86028A | Bracket Sub-assy, Television |
| 86050 | Antenna Assy, Television |
| 86101 | Cord Sub-assy, Antenna |
| 86101J | Cord Sub-assy, Antenna, NO.2 |
| 86300B | Antenna Assy, Amplifier, NO.1 |
| 86860C | Antenna Assy, Navigation |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
