Toyota Crown

2008-02 → 2012-12 · chassis GRS20#,GWS204 · catalogue 3311C0 · Japan

Supported model Data version 2012-12
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Roof Headlining & Silencer Pad

21 part groups · 2 illustrations

Illustrations

Figure 642282C 642282C 2008-02 → — Figure 642283C 642283C 2008-02 → —

Part groups

PNCDescription
63306 Trim Sub-assy, Sunshade
63310D Clip, Roof Headlining
63310H Clip(FOR ROOF HEADLINING)
63311C Headlining, Roof
63339A Cover, Roof Headlining Service Hole
63341 Pad, Roof Silencer, NO.1
63343 Pad, Roof Silencer, NO.3
63344 Pad, Roof Silencer, NO.4
63345 Pad, Roof Silencer, NO.5
63346 Pad, Roof Silencer, NO.6
63351B Pad, Roof Headlining
63351C Pad, Roof Headlining
63352 Pad, Roof Headlining, Center
63352D Pad, Roof Headlining, NO.2
63353C Pad, Roof Headlining, Center
63381E Retainer, Roof Headlining Trim, Front
63415C Grille, Roof Speaker, RH
63416B Grille, Roof Speaker, LH
66416 Spacer, Side Rail, Rear NO.3 RH
66426B Spacer, Side Rail, Rear NO.3 LH
75631L Garnish, Roof Top, Front
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
