Toyota Crown/Hybrid

2012-12 → 2018-04 · chassis ARS210,AWS21#,GRS21#,GWS214 · catalogue 3311D0 · Japan

Supported model Data version 2016-08
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Lock Cylinder Set

12 part groups · 2 illustrations

Illustrations

Figure 67A822B 67A822B 2012-12 → 2015-09 Figure 67A823B 67A823B 2015-09 → —

Part groups

PNCDescription
69503 Cylinder Set, Lock
69503B Key, Cut
69503D Key, Cut(CARD KEY)
69510 Cylinder Assy, Front Door Lock, RH
69550A Cylinder Assy, Glove Compartment Door Lock
69560A Cylinder Assy, Luggage Compartment Door Lock
89072B Housing Set, Door Control Transmitter (FOR SMART KEY)
89745A Battery, Transmitter
89745B Battery, Transmitter(CARD KEY)
8975B Cover, Transmitter Battery Housing
89904B Transmitter Sub-assy, Electrical Key
89904C Transmitter Sub-assy, Electrical Key(CARD KEY)
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
