Toyota Crown Crossover
2022-07 → present · chassis AZSH35,TZSH35 · catalogue 3311F0 · Japan
Supported model
Data version 2022-07
Side Moulding
70 part groups · 3 illustrations
Part groups
| PNC | Description |
|---|---|
| 52161W | Piece, Front Bumper |
| 53853 | Pad, Front Wheel Opening Extension, NO.3 |
| 67495C | Cover, Front Door Front Lower Frame, Upper RH |
| 67496C | Cover, Front Door Front Lower Frame, Upper LH |
| 67855E | Protector, Front Door Panel, RH |
| 67856E | Protector, Front Door Panel, LH |
| 67857L | Protector, Rear Door Panel, RH |
| 67858E | Protector, Rear Door Panel, LH |
| 75073 | Moulding Sub-assy, Front Door, Outside Lower RH |
| 75074 | Moulding Sub-assy, Front Door, Outside Lower LH |
| 75077 | Moulding Sub-assy, Rear Door Outside Lower RH |
| 75078 | Moulding Sub-assy, Rear Door Outside Lower LH |
| 75392A | Retainer, Outside Moulding, NO.1 |
| 75392E | Retainer, Outside Moulding, NO.1 |
| 75392F | Retainer, Outside Moulding |
| 75392G | Retainer, Outside Moulding, NO.1 |
| 75396 | Clip, Outside Moulding, NO.2 |
| 75397A | Clip, Outside Moulding, NO.3 |
| 75551E | Moulding, Roof Drip Side Finish, RH |
| 75552E | Moulding, Roof Drip Side Finish, LH |
| 75561 | Clip, Roof Drip Side Finish Moulding, NO.1 |
| 75601A | Moulding Sub-assy, Front Fender, RH |
| 75602A | Moulding Sub-assy, Front Fender, LH |
| 75605B | Moulding Sub-assy, Quarter Outside, RH |
| 75606B | Moulding Sub-assy, Quarter Outside, LH |
| 75611C | Moulding, Front Fender, Outside RH |
| 75612C | Moulding, Front Fender, Outside LH |
| 75625C | Pad, Front Fender Outside Moulding, Upper |
| 75651 | Moulding, Quarter, Outside RH |
| 75652 | Moulding, Quarter, Outside LH |
| 75691A | Pad, Front Fender Outside Moulding, RH |
| 75692A | Pad, Front Fender Outside Moulding, LH |
| 75695 | Pad, Quarter Outside Moulding |
| 75696 | Pad, Body Outside Moulding, NO.1 |
| 75696A | Pad, Body Outside Moulding |
| 75697C | Pad, Body Outside Moulding, LH |
| 75699 | Pad, Body Outside Moulding, NO.4 |
| 75710 | Moulding Assy, Front Door Belt, RH |
| 75720 | Moulding Assy, Front Door Belt, LH |
| 75730 | Moulding Assy, Rear Door Belt, RH |
| 75731A | Moulding, Front Door, Outside RH |
| 75732A | Moulding, Front Door, Outside LH |
| 75740 | Moulding Assy, Rear Door Belt, LH |
| 75741 | Moulding, Rear Door, Outside RH |
| 75742 | Moulding, Rear Door, Outside LH |
| 75743A | Moulding, Rear Door, Outside Upper Rear RH |
| 75744 | Moulding, Rear Door, Outside Upper Rear LH |
| 75753 | Moulding, Front Door Window Frame, Upper RH |
| 75754A | Moulding, Front Door Window Frame, Upper LH |
| 75755A | Moulding, Front Door Window Frame, RH(CENTER PILLAR SIDE) |
| 75756D | Moulding, Front Door Window Frame, LH(CENTER PILLAR SIDE) |
| 75761B | Moulding, Rear Door Window Frame, RH(CENTER PILLAR SIDE) |
| 75762B | Moulding, Rear Door Window Frame, LH(CENTER PILLAR SIDE) |
| 75763A | Moulding, Rear Door Window Frame, Upper RH |
| 75764A | Moulding, Rear Door Window Frame, Upper LH |
| 75765B | Moulding, Rear Door Window Frame, RH(REAR PILLAR SIDE) |
| 75766B | Moulding, Rear Door Window Frame, LH(REAR PILLAR SIDE) |
| 75787A | Pad, Front Door Outside Moulding, RH |
| 75788A | Pad, Front Door Outside Moulding, LH |
| 75792 | Clip, Door Window Frame Moulding |
| 75793 | Pad, Front Door Outside Moulding, Upper |
| 75797 | Pad, Rear Door Outside Moulding, Upper |
| 75797C | Pad, Rear Door Outside Moulding, Upper |
| 75798 | Pad, Rear Door Outside Moulding, Rear |
| 75850B | Screw, NO.3 |
| 75850E | Grommet, NO.3 |
| 75859 | Protector, Front Fender Side |
| 75860 | Protector, Front Fender Side, LH |
| 75867A | Clip, Rocker Panel Moulding |
| 75895A | Tape, Moulding, NO.1 |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
