Toyota Aristo

1991-10 → 1997-08 · chassis JZS147,UZS143 · catalogue 332180 · Japan

Discontinued model Data version 1998-01
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Air Cleaner

35 part groups · 3 illustrations

Illustrations

Figure MAF136D MAF136D 1991-10 → 1997-08 Figure 173689 173689 1991-10 → 1997-08 Figure MAF036B MAF036B 1992-10 → —

Part groups

PNCDescription
17305 Valve Sub-assy, Reed
17315B Gasket, Intake Air Control Valve
17321C Duct, Air Outlet, NO.1
17341F Hose, Air, NO.1
17341G Clamp OR Clip(FOR AIR HOSE, NO.1)
17341K Hose, Air, NO.1(FOR INTERCOOLER)
17342D Hose, Air, NO.2
17342E Clamp OR Clip(FOR AIR HOSE, NO.2)
17342F Hose, Air, NO.2(FOR INTERCOOLER)
17343D Hose, Air, NO.3
17344E Hose, Air, NO.4
17344K Clip(FOR AIR HOSE, NO.4)
17361J Tube, Air, NO.1
17362B Tube, Air, NO.2
17362C Tube, Air, NO.2
17363G Tube, Air, NO.3
17364 Tube, Air, NO.4
17376A Gasket, Air Tube
17378A Gasket, Air Tube, NO.3
17650F Valve Assy, Air By-pass, NO.2
17700 Cleaner Assy, Air
17705 Cap Sub-assy, Air Cleaner
17801 Element Sub-assy, Air Cleaner Filter
17849 Gasket, Intake Air Connector
17861 Connector, Intake Air
17861D Clamp(FOR INTAKE AIR CONNECTOR)
17875 Pipe, Intake Air Connector
17881 Hose, Air Cleaner, NO.1
17881A Clamp(FOR AIR CLEANER HOSE, NO.1)
17882 Hose, Air Cleaner, NO.2
17890 Hose Assy, Air Cleaner, NO.2
17909 Duct Sub-assy, Intercooler Cooling Air
17940D Intercooler Assy
22250 Meter Assy, Intake Air Flow
22275 Gasket, Air Flow Meter
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
