Toyota Aristo

1991-10 → 1997-08 · chassis JZS147,UZS143 · catalogue 332180 · Japan

Discontinued model Data version 1998-01
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Caution Plate (EXTERIOR & INTERIOR)

18 part groups · 2 illustrations

Illustrations

Figure 746064 746064 1991-10 → — Figure MBV962C MBV962C 1991-10 → —

Part groups

PNCDescription
11277A Plate, Engine Specification, NO.2
11283B Label, Leak Detection Pump Information
11286B Plate, Engine Specification
11291B Plate, Engine Name
11293D Label, Engine Caution
11296C Label, Engine Service Information
13564 Label, Timing Belt Replacement Information
15369A Label, Engine Oil Information
17791A Label, Maintenance Information
45197A Label, Airbag Caution
48969 Label, Jack UP Caution
74541 Plate, Tire Pressure Caution
74541E Plate, Compact Spare Tire Caution
74562 Plate, Emission Control System Information
74571 Plate, Brake Fluid Caution
74579A Label, Unleaded Fuel Information
74597 Label, Driver & Passenger Airbag Caution
75341C Plate, Hood Name
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
