Toyota Crown Comfort/Sed

1995-12 → 2018-01 · chassis GXS1#,LXS11,SXS1#,YXS1#,GBS12,TSS1# · catalogue 333110 · Japan

Discontinued model Data version 2018-07
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Caution Plate & Name Plate (ENGINE)

13 part groups · 2 illustrations

Illustrations

Figure 172836K 172836K 1995-12 → — Figure 175796C 175796C 1995-12 → —

Part groups

PNCDescription
11283 Plate, Turbocharger Caution
11289 Plate, Spark Plug Caution
11292 Plate, Engine Name, NO.2
11293 Plate, Engine Caution & Engine Name
11293A Plate, Engine Caution
11295 Label, Engine Service Notice
11296A Label, Engine Service Information
11297B Label, Engine Service Information, NO.2
16448 Plate, Radiator Caution
16701G Label, Caution
17700C Plate, Air Cleaner Caution (FOR ENGINE MODEL)
17700D Plate, Engine Caution
17791 Label, Maintenance Information
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
