Toyota Majesta
2009-03 → 2013-07 · chassis URS206,UZS207 · catalogue 335110 · Japan
Supported model
Data version 2014-01
Rear Seat & Seat Track
53 part groups · 6 illustrations
Part groups
| PNC | Description |
|---|---|
| 71075B | Cover, Rear Seat Cushion (FOR BENCH TYPE) |
| 71075S | Cover, Rear Seat Cushion, RH (FOR SEPARATE TYPE) |
| 71076S | Cover, Rear Seat Cushion, LH (FOR SEPARATE TYPE) |
| 71077S | Cover, Rear Seatback, RH (FOR SEPARATE TYPE) |
| 71078S | Cover, Rear Seatback, LH(FOR SEPARATE TYPE) |
| 71266 | Gusset, Rear Seatback Frame |
| 71281A | Hinge, Rear Seat Center Armrest |
| 71305S | Frame Sub-assy, Center Seatback |
| 71480S | Back Assy, Rear Seat, RH (FOR SEPARATE TYPE) |
| 71490S | Back Assy, Rear Seat, LH (FOR SEPARATE TYPE) |
| 71611 | Pad, Rear Seat Cushion |
| 71611A | Pad, Rear Seat Cushion, RH |
| 71612A | Pad, Rear Seat Cushion, LH |
| 71616A | Pad, Rear Seat Cushion |
| 71628E | Spacer, Rear Seat Cushion |
| 71628J | Spacer, Rear Seatback |
| 71651S | Pad, Rear Seatback, RH(FOR SEPARATE TYPE) |
| 71652S | Pad, Rear Seatback, LH(FOR SEPARATE TYPE) |
| 71695A | Protector, Rear Seat, NO.1 RH |
| 71695B | Protector, Rear Seat, NO.1 LH |
| 71865 | Bezel, Rear Seat Cover, NO.1 |
| 71866A | Bezel, Rear Seat Cover, NO.2 |
| 71907A | Adjuster Sub-assy, Rear Seat Headrest, NO.1 |
| 71907B | Adjuster Sub-assy, Rear Seat Headrest, NO.2 |
| 71931A | Support, Rear Seat Headrest |
| 71940A | Headrest Assy, Rear Seat |
| 71956B | Support, Rear Seat Headrest |
| 71970 | Headrest Assy, Rear Seat |
| 72030 | Adjuster Assy, Rear NO.1 Seat |
| 72693 | Hook, Rear Seat Cushion Lock |
| 72730A | Adjuster Assy, Rear Seat Reclining, RH |
| 72740A | Adjuster Assy, Rear Seat Reclining, LH |
| 72803D | Panel Sub-assy, Rear Seat Center Armrest |
| 72805B | Door Sub-assy, Rear Seat Center Armrest |
| 72806B | Holder Sub-assy, Rear Seat Center Armrest Cup |
| 72809 | Lock Sub-assy, Center Armrest |
| 72830 | Armrest Assy, Rear Seat, Center |
| 72860 | Box Assy, Rear Seat Center Armrest |
| 72861 | Trim, Center Armrest Corner |
| 72863 | Box, Rear Seat Center Armrest |
| 72978 | Cover, NO.2 Center Seatback |
| 72996 | Cover, Rear Seatback, RH |
| 73705 | Bracket Sub-assy, Child Restraint Seat Anchor, RH |
| 73706 | Bracket Sub-assy, Child Restraint Seat Anchor, LH |
| 79959B | Cover, Rear Seat Leg, LH |
| 85801A | Blower Sub-assy, Seat Cushion Climate, RH |
| 85802A | Blower Sub-assy, Seat Cushion Climate, LH |
| 85803A | Blower Sub-assy, Seatback Climate, RH |
| 85804A | Blower Sub-assy, Seatback Climate, LH |
| 85820X | Motor Assy, Power Seat |
| 85862B | Blower, Seat Climate Control, RH |
| 85863B | Blower, Seat Climate Control, LH |
| 87519A | Bracket, Seat Heater Connector Clamp |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
