Toyota Crown Sedan
2023-11 → present · chassis AZSH32,KZSM30 · catalogue 33B110 · Japan
Supported model
Data version 2023-11
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 23826 — Hose, Fuel Vapor Feed, NO.1 | ||||
| 23826-25490 |
Hose, Fuel Vapor Feed, NO.1
2023-11 → —
|
A25 AZSH32 | ¥1,950 | |
| 23827A — Hose, Fuel Vapor Feed, NO.2 | ||||
| 23826-25100 |
Hose, Fuel Vapor Feed, NO.2
2023-11 → —
|
A25 AZSH32 | ¥630 | |
| 25860 — Valve Assy, Vacuum Switching, NO.1 | ||||
| 25860-25050 |
Valve Assy, Vacuum Switching, NO.1
2023-11 → —
|
A25 AZSH32 | ¥3,480 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
