Toyota Crown Sedan
2023-11 → present · chassis AZSH32,KZSM30 · catalogue 33B110 · Japan
Supported model
Data version 2023-11
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 48131 — Spring, Front Coil, RH | ||||
| 48131-30G70 |
Spring, Front Coil, RH
2023-11 → —
|
AZSH32 | ¥5,700 | |
| 48131-30G80 |
Spring, Front Coil, RH
2023-11 → —
|
KZSM30 | ¥5,700 | |
| 48132 — Spring, Front Coil, LH | ||||
| 48131-30G70 |
Spring, Front Coil, LH
2023-11 → —
|
AZSH32 | ¥5,700 | |
| 48131-30G80 |
Spring, Front Coil, LH
2023-11 → —
|
KZSM30 | ¥5,700 | |
| 48158B — Insulator, Front Coil Spring, Lower RH | ||||
| 48158-30020 |
Insulator, Front Coil Spring, Lower RH
2023-11 → —
|
AZSH32,KZSM30 | ¥300 | |
| 48158C — Insulator, Front Coil Spring, Lower LH | ||||
| 48158-30020 |
Insulator, Front Coil Spring, Lower LH
2023-11 → —
|
AZSH32,KZSM30 | ¥300 | |
| 48510 — Absorber Assy, Shock, Front RH | ||||
| 48510-80C40 note |
Absorber Assy, Shock, Front RH
2023-11 → —
|
KZSM30 | ¥56,300 | |
| 48510-80C43 note |
Absorber Assy, Shock, Front RH
2023-11 → —
|
AZSH32 | ¥59,900 | |
| 48520 — Absorber Assy, Shock, Front LH | ||||
| 48520-80792 note |
Absorber Assy, Shock, Front LH
2023-11 → —
|
KZSM30 | ¥56,300 | |
| 48520-80794 note |
Absorber Assy, Shock, Front LH
2023-11 → —
|
AZSH32 | ¥59,900 | |
| 48603A — Nut(FOR FRONT SUSPENSION SUPPORT) | ||||
| 90178-10039 |
Nut(FOR FRONT SUSPENSION SUPPORT)
2023-11 → —
|
AZSH32,KZSM30 | ¥100 | |
| 48680 — Support Assy, Front Suspension | ||||
| 48680-30600 |
Support Assy, Front Suspension
2023-11 → —
|
AZSH32 | ¥4,730 | |
| 48680-62010 note |
Support Assy, Front Suspension
2023-11 → —
|
KZSM30 | ¥5,100 | |
| 48680-62020 note |
Support Assy, Front Suspension
2023-11 → —
|
KZSM30 | ¥5,100 | |
| 48680A — Nut(FOR FRONT SUPPORT TO FRONT SHOCK ABSORBER) | ||||
| 90177-12002 |
Nut(FOR FRONT SUPPORT TO FRONT SHOCK ABSORBER)
2023-11 → —
|
AZSH32,KZSM30 | ¥90 | |
| 48810 — Link Assy, Front Stabilizer, LH | ||||
| 48810-11010 |
Link Assy, Front Stabilizer, LH
2023-11 → —
|
AZSH32 | ¥5,100 | |
| 48810-50040 |
Link Assy, Front Stabilizer, LH
2023-11 → —
|
KZSM30 | ¥5,100 | |
| 48811 — Bar, Stabilizer, Front | ||||
| 48804-11040 |
Bar, Stabilizer, Front
2023-11 → —
|
AZSH32 | ¥9,900 | |
| 48804-50010 |
Bar, Stabilizer, Front
2023-11 → —
|
KZSM30 | ¥12,400 | |
| 48820B — Link Assy, Front Stabilizer, RH | ||||
| 48820-11010 |
Link Assy, Front Stabilizer, RH
2023-11 → —
|
AZSH32 | ¥5,100 | |
| 48820-50050 |
Link Assy, Front Stabilizer, RH
2023-11 → —
|
KZSM30 | ¥5,100 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
