Toyota Crown Sedan
2023-11 → present · chassis AZSH32,KZSM30 · catalogue 33B110 · Japan
Supported model
Data version 2023-11
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 55111 — Panel, Dash | ||||
| 55111-50901 |
Panel, Dash
2023-11 → —
|
AZSH32,KZSM30 | ¥13,300 | |
| 55111C — Bolt, Weld(FOR DASH PANEL) | ||||
| 90115-06166 |
Bolt, Weld(FOR DASH PANEL)
2023-11 → —
|
AZSH32,KZSM30 | ¥90 | |
| 55111D — Bolt, Weld(FOR DASH PANEL) | ||||
| 90115-06306 |
Bolt, Weld(FOR DASH PANEL)
2023-11 → —
|
AZSH32,KZSM30 | ¥80 | |
| 55111E — Bolt, Weld(FOR DASH PANEL) | ||||
| 90115-08143 |
Bolt, Weld(FOR DASH PANEL)
2023-11 → —
|
AZSH32,KZSM30 | ¥80 | |
| 55111F — Nut, Weld(FOR DASH PANEL) | ||||
| 90174-06002 |
Nut, Weld(FOR DASH PANEL)
2023-11 → —
|
AZSH32,KZSM30 | ¥70 | |
| 55111G — Nut, Cap(FOR DASH PANEL) | ||||
| 90176-08055 |
Nut, Cap(FOR DASH PANEL)
2023-11 → —
|
AZSH32,KZSM30 | ¥100 | |
| 55210 — Insulator Assy, Dash Panel | ||||
| 55210-50190 |
Insulator Assy, Dash Panel
2023-11 → —
|
AZSH32 | ¥17,500 | |
| 55210-62040 |
Insulator Assy, Dash Panel
2023-11 → —
|
KZSM30 | ¥15,600 | |
| 55210A — Clip | ||||
| 90467-11122 |
Clip
2023-11 → —
|
AZSH32,KZSM30 | ¥100 | |
| 55223A — Insulator, Dash Panel, Outer | ||||
| 55223-50120 |
Insulator, Dash Panel, Outer
2023-11 → —
|
AZSH32 | ¥5,900 | |
| 55223-62020 |
Insulator, Dash Panel, Outer
2023-11 → —
|
KZSM30 | ¥3,560 | |
| 55223C — Clip | ||||
| 90467-06206-C0 note |
Clip
2023-11 → —
|
AZSH32,KZSM30 | ¥80 | |
| 55241 — Silencer, Front Panel Side, NO.1 RH | ||||
| 55241-62010 |
Silencer, Front Panel Side, NO.1 RH
2023-11 → —
|
AZSH32,KZSM30 | ¥1,610 | |
| 55241B — Clip, Front Panel Side Silencer | ||||
| 90467-13079 |
Clip, Front Panel Side Silencer
2023-11 → —
|
AZSH32,KZSM30 | ¥120 | |
| 55242 — Silencer, Front Panel Side, NO.1 LH | ||||
| 55242-62010 |
Silencer, Front Panel Side, NO.1 LH
2023-11 → —
|
AZSH32,KZSM30 | ¥1,610 | |
| 55242B — Clip, Front Panel Side Silencer | ||||
| 90467-13079 |
Clip, Front Panel Side Silencer
2023-11 → —
|
AZSH32,KZSM30 | ¥120 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
