Toyota Crown Sedan
2023-11 → present · chassis AZSH32,KZSM30 · catalogue 33B110 · Japan
Supported model
Data version 2023-11
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 53851D — Pad, Front Wheel Opening Extension, RH | ||||
| 53851-62040 |
Pad, Front Wheel Opening Extension, RH
2023-11 → —
|
AZSH32,KZSM30 | ¥1,880 | |
| 53852B — Pad, Front Wheel Opening Extension, LH | ||||
| 53852-62040 |
Pad, Front Wheel Opening Extension, LH
2023-11 → —
|
AZSH32,KZSM30 | ¥1,880 | |
| 53875A — Liner, Front Fender, RH | ||||
| 53805-30160 |
Liner, Front Fender, RH
2023-11 → —
|
AZSH32,KZSM30 | ¥9,100 | |
| 53875P — Screw, NO.1 | ||||
| 90159-60477 |
Screw, NO.1
2023-11 → —
|
AZSH32,KZSM30 | ¥70 | |
| 53875Q — Screw, NO.2 | ||||
| 90159-60623 |
Screw, NO.2
2023-11 → —
|
AZSH32,KZSM30 | ¥60 | |
| 53875S — Grommet, NO.1 | ||||
| 90189-06145 |
Grommet, NO.1
2023-11 → —
|
AZSH32,KZSM30 | ¥80 | |
| 53876A — Liner, Front Fender, LH | ||||
| 53806-30210 |
Liner, Front Fender, LH
2023-11 → —
|
AZSH32,KZSM30 | ¥9,100 | |
| 53879A — Retainer, Front Fender Liner | ||||
| 53879-50010 |
Retainer, Front Fender Liner
2023-11 → —
|
AZSH32,KZSM30 | ¥70 | |
| 53879R — Retainer, Front Fender Liner | ||||
| 53879-47020 |
Retainer, Front Fender Liner
2023-11 → —
|
AZSH32,KZSM30 | ¥160 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
