Toyota Crown Sedan
2023-11 → present · chassis AZSH32,KZSM30 · catalogue 33B110 · Japan
Supported model
Data version 2023-11
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 74406B — Clamp Sub-assy, Battery Hold Down | ||||
| 74406-62010 |
Clamp Sub-assy, Battery Hold Down
2023-11 → —
|
KZSM30 | ¥460 | |
| 74410 — Carrier Assy, Battery | ||||
| 74410-30110 |
Carrier Assy, Battery
2023-11 → —
|
AZSH32 | ¥10,000 | |
| 74410-62020 |
Carrier Assy, Battery
2023-11 → —
|
KZSM30 | ¥7,700 | |
| 74481A — Clamp, Battery | ||||
| 74481-15010 |
Clamp, Battery
2023-11 → —
|
KZSM30 | ¥810 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
