Toyota Crown Sedan
2023-11 → present · chassis AZSH32,KZSM30 · catalogue 33B110 · Japan
Supported model
Data version 2023-11
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 52620 — Chamber Assy, Pedestrian Detection | ||||
| 52620-62010 |
Chamber Assy, Pedestrian Detection
2023-11 → —
|
AZSH32,KZSM30 | — | |
| 89170A — Computer Assy, Airbag | ||||
| 89170-30J70 note |
Computer Assy, Airbag
2023-11 → 2025-06
ended
|
AZSH32,KZSM30 | ¥25,400 | |
| 89173A — Sensor, Airbag, Front RH | ||||
| 89173-59335 |
Sensor, Airbag, Front RH
2023-11 → —
|
AZSH32,KZSM30 | ¥4,110 | |
| 89174A — Sensor, Airbag, Front LH | ||||
| 89173-59335 |
Sensor, Airbag, Front LH
2023-11 → —
|
AZSH32,KZSM30 | ¥4,110 | |
| 89831 — Sensor, Side Airbag, RH, NO.1 | ||||
| 89831-62020 |
Sensor, Side Airbag, RH, NO.1
2023-11 → —
|
AZSH32,KZSM30 | ¥4,110 | |
| 89831A — Sensor, Side Airbag, LH, NO.1 | ||||
| 89831-62020 |
Sensor, Side Airbag, LH, NO.1
2023-11 → —
|
AZSH32,KZSM30 | ¥4,110 | |
| 89831B — Sensor, Side Airbag, RH, NO.2 | ||||
| 89831-52130 |
Sensor, Side Airbag, RH, NO.2
2023-11 → —
|
AZSH32,KZSM30 | ¥4,110 | |
| 89831C — Sensor, Side Airbag, LH, NO.2 | ||||
| 89831-52130 |
Sensor, Side Airbag, LH, NO.2
2023-11 → —
|
AZSH32,KZSM30 | ¥4,110 | |
| 8983A — Sensor, Side Airbag Pressure, RH | ||||
| 8983A-52020 |
Sensor, Side Airbag Pressure, RH
2023-11 → —
|
AZSH32,KZSM30 | ¥4,110 | |
| 8983AA — Sensor, Side Airbag Pressure, LH | ||||
| 8983A-52020 |
Sensor, Side Airbag Pressure, LH
2023-11 → —
|
AZSH32,KZSM30 | ¥4,110 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
