Toyota Crown Sedan
2023-11 → present · chassis AZSH32,KZSM30 · catalogue 33B110 · Japan
Supported model
Data version 2023-11
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 86011A — Condenser, Radio Setting | ||||
| 90980-04211 |
Condenser, Radio Setting
2023-11 → —
|
AZSH32,KZSM30 | ¥1,150 | |
| 86011V — Condenser, Radio Setting | ||||
| 90980-04213 |
Condenser, Radio Setting
2023-11 → —
|
AZSH32,KZSM30 | ¥1,150 | |
| 86190F — Adapter Assy, Stereo Jack | ||||
| 86190-12080 |
Adapter Assy, Stereo Jack
2023-11 → —
|
AZSH32,KZSM30 | ¥3,780 | |
| 86280K — Amplifier Assy, Stereo Component | ||||
| 86280-30A50 |
Amplifier Assy, Stereo Component
2023-11 → —
|
AZSH32,KZSM30 Z | ¥83,000 | |
| 86280-30A60 |
Amplifier Assy, Stereo Component
2023-11 → —
|
AZSH32 G | ¥83,000 | |
| 86285 — Bracket, Amplifier, NO.1 | ||||
| 86285-30480 |
Bracket, Amplifier, NO.1
2023-11 → —
|
KZSM30 | ¥1,310 | |
| 86285-30490 |
Bracket, Amplifier, NO.1
2023-11 → —
|
AZSH32 | ¥1,200 | |
| 86286 — Bracket, Amplifier, NO.2 | ||||
| 86286-30210 |
Bracket, Amplifier, NO.2
2023-11 → —
|
AZSH32 | ¥1,450 | |
| 86286-62040 |
Bracket, Amplifier, NO.2
2023-11 → —
|
KZSM30 | ¥910 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
