Toyota Crown Sedan
2023-11 → present · chassis AZSH32,KZSM30 · catalogue 33B110 · Japan
Supported model
Data version 2023-11
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 86160 — Speaker Assy, Front NO.1 | ||||
| 86150-30700 |
Speaker Assy, Front NO.1
2023-11 → —
|
AZSH32,KZSM30 Z | ¥9,800 | |
| 86160-30F60 |
Speaker Assy, Front NO.1
2023-11 → —
|
AZSH32 G | ¥6,300 | |
| 86160B — Speaker Assy, Rear | ||||
| 86150-30720 |
Speaker Assy, Rear
2023-11 → —
|
AZSH32,KZSM30 Z | ¥7,600 | |
| 86160-30F40 |
Speaker Assy, Rear
2023-11 → —
|
AZSH32 G | ¥6,300 | |
| 86160J — Speaker Assy, Front NO.3 | ||||
| 86150-30750 |
Speaker Assy, Front NO.3
2023-11 → —
|
AZSH32,KZSM30 Z | ¥7,600 | |
| 86160-30F20 |
Speaker Assy, Front NO.3
2023-11 → —
|
AZSH32 G | ¥6,300 | |
| 86160L — Speaker Assy, Front NO.4 | ||||
| 86150-30710 |
Speaker Assy, Front NO.4
2023-11 → —
|
AZSH32,KZSM30 Z | ¥6,300 | |
| 86160P — Speaker Assy, Front NO.2 | ||||
| 86150-30740 |
Speaker Assy, Front NO.2
2023-11 → —
|
AZSH32,KZSM30 Z | ¥7,600 | |
| 86160-30F30 |
Speaker Assy, Front NO.2
2023-11 → —
|
AZSH32 G | ¥6,300 | |
| 86160S — Speaker Set | ||||
| 86150-30680 |
Speaker Set
2023-11 → —
|
AZSH32,KZSM30 Z | ¥7,600 | |
| 86160Y — Speaker Assy, Rear NO.2 | ||||
| 86150-30710 |
Speaker Assy, Rear NO.2
2023-11 → —
|
AZSH32,KZSM30 Z | ¥6,300 | |
| 86160Z — Speaker Assy, Rear NO.3 | ||||
| 86150-30670 |
Speaker Assy, Rear NO.3
2023-11 → —
|
AZSH32,KZSM30 | ¥12,800 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
