Toyota Crown Sedan
2023-11 → present · chassis AZSH32,KZSM30 · catalogue 33B110 · Japan
Supported model
Data version 2023-11
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 86461 — Hood, Forward Recognition | ||||
| 86461-42040 |
Hood, Forward Recognition
2023-11 → —
|
AZSH32,KZSM30 | ¥750 | |
| 86466D — Cover, Forward Recognition, NO.1 | ||||
| 86467-30040 |
Cover, Forward Recognition, NO.1
2023-11 → —
|
AZSH32,KZSM30 | ¥1,350 | |
| 86466E — Cover, Forward Recognition, NO.2 | ||||
| 86466-30020 |
Cover, Forward Recognition, NO.2
2023-11 → —
|
AZSH32,KZSM30 | ¥2,960 | |
| 8646C — Camera, Forward Recognition | ||||
| 8646C-30320 note |
Camera, Forward Recognition
2023-11 → 2025-06
ended
|
AZSH32,KZSM30 | ¥43,000 | |
| 867N0 — Computer Assy, Drive Recorder | ||||
| 867N0-30040 |
Computer Assy, Drive Recorder
2023-11 → —
|
AZSH32,KZSM30 | ¥46,800 | |
| 867N5 — Cover, Drive Recorder | ||||
| 867N5-30010 |
Cover, Drive Recorder
2023-11 → —
|
AZSH32,KZSM30 | ¥2,490 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
