Toyota Crown Estate

2024-06 → present · chassis AZSH3# · catalogue 33C110 · Japan

Supported model Data version 2024-07

Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Switch & Relay & Computer

146 part groups · 13 illustrations

Illustrations

Part groups

PNC	Description
28371B	Relay, Igr
28371J	Relay, Igb
28371L	Relay, Igp
28800R	Relay, Battery Fan
28850C	Sensor Assy, Battery State
28859A	Holder, Battery Current Sensor
28911	Bracket, Integration Control Supply, NO.1
28911A	Bracket, Integration Control Supply, NO.2
28912	Supply, Integration Control
81713	Holder, Fusee
82210N	Instrument Panel Fusible Link
82600D	Instrument Panel Fuse
82600F	Fuse, Fuse Block
82600L	Luggage Room Fuse
82610A	Block Assy, Fuse
82611	Cover, Fuse Block
82613A	Block, Fuse Base
82616	Puller, Fuse
82620F	Block Assy, Fusible Link
82644	Computer, Semiconductor Power Integration
82660B	Block Assy, Relay
82662A	Cover, Relay Block, Upper, NO.1
82662B	Cover, Relay Block, Upper, NO.2
82662C	Cover, Relay Block, Upper, NO.3
82663	Cover, Relay Block, Lower
82663A	Cover, Relay Block, Lower, NO.2
82663C	Cover, Relay Block Lower, NO.4
82663D	Cover, Relay Block, Lower, NO.5
82663K	Cover, Relay Block, Lower, NO.6
82670A	Block Assy, Junction, NO.1
82672A	Cover, Junction Block
82672K	Cover, Power Distribution Box
82673C	Bracket, Junction Block
82715W	Bracket, Wiring Harness Clamp
82715X	Bracket, Wiring Harness Clamp, NO.2
82730G	Box Assy, Power Distribution
82740	Block Assy, Engine Room Relay
82740A	Block Assy, Engine Room Relay, NO.2
82877	Box, Computer Integration, RH
82878	Box, Computer Integration, LH
83320	Gage Assy, Fuel Sender
83650	Fusee
84040	Master Switch Assy,Multiplex Network
84150D	Switch Assy, Headlamp Cleaner
84152	Switch, Headlamp Leveling
84153	Switch, Auto High Beam
84233	Switch Assy, Courtesy Lamp (FOR FRONT DOOR)
84250A	Switch Assy, Steering Pad
84306	Cable Sub-assy, Spiral
84307	Cable Sub-assy, Spiral W/Sensor
84319	Housing, Steering Wheel Switch
84329	Switch, Turn Signal
84330	Switch Assy, Hazard Warning Signal
84340	Switch Assy, Stop Lamp
84345	Adjuster, Stop Lamp Switch Mounting
84390B	Switch Assy, Electric Parking Brake
84485C	Switch, Power Outlet
84523	Wire, Switch NO.1
84610G	Switch Assy, Transmission Shift, NO.1
84610H	Switch Assy, Transmission Shift, NO.2
84650	Switch Assy, Windshield Wiper
84751R	Switch, Seat Heater(REAR)
84794	Switch, FR Wiper Deicer
84794A	Relay, FR Wiper Deicer
84810	Switch Assy, Power Window Regulator
84810D	Switch Assy, Power Window Regulator, Rear
84840G	Switch Assy, Back Door Opener
84841A	Switch, Fuel Lid Opener
84870A	Switch Assy, Outer Mirror
84920	Switch Assy, Power Seat
84921N	Knob, Power Seat Switch, RH (FOR RECLINING)
84921P	Knob, Power Seat Switch, RH (FOR SLIDE & VERTICAL)
84921Q	Knob, Power Seat Switch, LH (FOR RECLINING)
84921R	Knob, Power Seat Switch, LH (FOR SLIDE & VERTICAL)
84922B	Switch, Front Power Seat, RH
84922C	Switch, Front Power Seat, LH
84927	Switch, Seat Memory
84930P	Switch Assy, Door Control
84934B	Cover, Door Control Switch
84941A	Base, Switch
84966	Switch, Power Back Door Control
84966A	Switch, Power Back Door Control, NO.1
84970	Switch Assy, Combination
84975	Switch, Trip
85530	Socket Assy, Power Outlet, NO.1
85531	Socket, Power Outlet
85531A	Socket, Power Outlet, NO.2
85532B	Socket, Usb Charger
85532C	Socket, Usb Charger, NO.2
85535B	Cover, Power Outlet Socket, NO.1
85910V	Relay, Seat Heater
85912K	Relay, Vvt
85924C	Relay, Igct
85924H	Relay, Igct-scene
85924J	Relay, Dcb
85925D	Relay, Ptc Heater
85925F	Relay, Ptc Heater NO.2
85925G	Relay, Ptc Heater NO.3
85934	Relay, Magnet-clutch
85941	Relay, Windshield Washer
85942	Relay, Headlamp Cleaner Control
85948	Relay, Windshield Wiper
86210D	Fuse, High Voltage
86247B	Bracket, Voltage Inverter
86247C	Bracket, Voltage Inverter, NO.2
8624A	Inverter, Voltage
86530	Relay Assy, Horn
869A1	Computer, Intelligent Transport Systems Communication
88161	Bracket, Blind Spot Monitor, RH
88162	Sensor, Blind Spot Monitor, RH
88171	Bracket, Blind Spot Monitor, LH
88172	Sensor, Blind Spot Monitor, LH
886A0	Computer Assy, Heat Pump
89111	Computer, Network Gateway
89120A	Sensor, Automatic Light Control
891B0	Sensor Assy, Kick Door Control
891B0B	Retainer, Kick Door Control Sensor
89221	Computer, Multiplex Network Body
89222	Computer, Multiplex Network Door, Front RH
89222A	Computer, Multiplex Network Door
89223	Computer, Multiplex Network Door, Front LH
89227	Computer, Multiplex Tilt & Telescopic
89235A	Switch, Tilt & Telescopic
89245B	Sensor, Steering
89422A	Sensor, Water Temperature
89461	Sensor, Vapor Pressure
89467B	Sensor, Air Fuel Ratio
89467C	Sensor, Air Fuel Ratio, NO.2
894C7	Bracket, Shift Control Computer, NO.1
894C8	Bracket, Shift Control Computer, NO.2
894D1	Supply, Shift Control
89561F	Relay, Electronic Fuel Injection Main, NO.1
89561G	Relay, Electronic Fuel Injection Main, NO.2
89561H	Relay, Electronic Fuel Injection Main, NO.3
89611	Switch, Push Start
89615	Sensor, Knock Control
89701B	Relay, Plugin Charge Control
89710C	Computer Assy, Position Control, RH
89730A	Relay(FOR SECURITY WARNING)
89747E	Buzzer, Power Back Door Warning
89870E	Relay, Electronic Driver Unit
C8570B	Relay Assy, Drive Control, NO.1
G1167A	Relay (FOR OIL PUMP MOTOR)
G3840B	Relay Assy, Electric Vehicle
G9020E	Relay, Hybrid Water Pump
G9118R	Label, Unit Controller Caution, NO.1

PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
