Toyota Century
1967-11 → 1982-09 · chassis VG2#,3# · catalogue 341110 · Japan
Discontinued model
Data version 1983-03
Transmission Gear (MTM)
79 part groups · 5 illustrations
Part groups
| PNC | Description |
|---|---|
| 33031 | Hub Assy, Synchronizer, NO.1 |
| 33105 | Baffle Sub-assy, Extension Housing Oil |
| 33311 | Shaft, Input |
| 33311A | Bearing (FOR INPUT SHAFT FRONT) |
| 33311B | Ring, Shaft Snap (FOR FRONT BEARING) |
| 33311C | Ring, Hole Snap (FOR NEEDLE ROLLER) |
| 33311D | Bearing, Input Shaft |
| 33311G | Ring, Shaft Snap (FOR FRONT BEARING) |
| 33321 | Shaft, Output |
| 33321A | Bearing (FOR OUTPUT SHAFT REAR) |
| 33321B | Ring, Shaft Snap (FOR OUTPUT SHAFT BEARING) |
| 33321C | Ring, Shaft Snap (FOR OUTPUT SHAFT BEARING) |
| 33321D | Ring, Shaft Snap (FOR CLUTCH HUB SET) |
| 33321E | Spacer (FOR 1ST GEAR TO BEARING) |
| 33321F | Ring, Shaft Snap (FOR CLUTCH HUB TO 1ST GEAR) |
| 33321G | Nut (FOR MANUAL TRANSMISSION OUTPUT SHAFT REAR SET) |
| 33321H | Shim (FOR OUTPUT SHAFT REAR BEARING) |
| 33321S | Spacer (FOR GEAR STOPPER) |
| 33321W | Nut, Output Shaft Front Set |
| 33331 | Gear, Reverse |
| 33331A | Bearing (FOR REVERSE GEAR) |
| 33331B | Ring, Set (FOR REVERSE GEAR) |
| 33332 | Gear, 2ND |
| 33332B | Bearing, Needle Roller (FOR 2ND GEAR) |
| 33333 | Gear, 3RD |
| 33335 | Gear, 1ST |
| 33335C | Bearing, Needle Roller(FOR 1ST GEAR) |
| 33341 | Washer, 2ND & 3RD Gear Thrust |
| 33343 | Bush, 3RD & 2ND Gear |
| 33345 | Bush, 1ST Gear |
| 33346 | Bush, 2ND Gear |
| 33346A | Pin, Straight (FOR 2ND GEAR BUSH) |
| 33347 | Washer, 1ST & 2ND Gear Thrust |
| 33352 | Race, Reverse Gear Bearing Inner |
| 33352A | Key OR Ball, Reverse Gear Bearing Inner Race Lock |
| 33355 | Race, 1ST Gear Bearing Inner |
| 33355A | Key OR Ball, 1ST Gear Bearing Inner Race Lock |
| 33361 | Hub, Transmission Clutch, NO.1 |
| 33362 | Hub, Transmission Clutch, NO.2 |
| 33363 | Sleeve, Transmission Hub, NO.1 |
| 33364 | Sleeve, Transmission Hub, NO.2 |
| 33365 | Key, Synchromesh Shifting, NO.1 |
| 33366 | Key, Synchromesh Shifting, NO.2 |
| 33367 | Ring, Synchronizer, NO.1 |
| 33368 | Ring, Synchronizer, NO.2 |
| 33371 | Spring, Synchromesh Shifting Key, NO.1 |
| 33385 | Retainer, Shifting Key |
| 33391 | Spring, Synchromesh Shifting Key, NO.2 |
| 33393 | Hub, Transmission Clutch, NO.3 |
| 33395 | Sleeve, Transmission Hub, NO.3 |
| 33402 | Gear Sub-assy, Reverse Idler |
| 33402A | Bush OR Bearing (FOR REVERSE IDLER GEAR) |
| 33411 | Countershaft |
| 33411A | Bearing OR Roller(FOR COUNTER GEAR FRONT) |
| 33411B | Spacer(FOR COUNTER GEAR BEARING) |
| 33411C | Key, Woodruff(FOR COUNTER GEAR SHAFT) |
| 33411D | Ring, Counter Gear Front Bearing Snap, NO.1 |
| 33411E | Nut(FOR COUNTER GEAR SHAFT) |
| 33411F | Bolt(FOR COUNTER GEAR SHAFT SETTING) |
| 33411G | Shim(FOR COUNTER GEAR SHAFT BEARING SETTING) |
| 33411H | Bearing OR Roller(FOR COUNTER GEAR REAR) |
| 33421 | Gear, Counter |
| 33421A | Tube(FOR COUNTER GEAR) |
| 33421B | Spring, Counter Gear Thrust Corn |
| 33421C | Shim(FOR COUNTER GEAR THRUST CORN SPRING) |
| 33425 | Gear, Countershaft Reverse |
| 33433 | Plate, Counter Gear Rear Bearing Lock |
| 33435 | Washer, Counter Gear Case Side Thrust |
| 33441 | Washer, Counter Gear Side Thrust, NO.1 |
| 33451 | Shaft, Reverse Idler Gear |
| 33451A | Key, Woodruff (FOR REVERSE IDLER GEAR SHAFT) |
| 33451D | Ring, Shaft Snap (FOR REVERSE IDLER GEAR SHAFT) |
| 33452 | Stopper, Reverse Idler Gear Shaft |
| 33453 | Spacer, Reverse Idler Gear Shaft |
| 33454 | Bolt, Shaft Retaining |
| 33462 | Washer, Reverse Idler Thrust |
| 33481 | Gear, Speedometer Drive (MTM) |
| 33481A | Key OR Ball, Speedometer Drive Gear (MTM) |
| 33481B | Ring OR Spacer (FOR MTM SPEEDOMETER DRIVE GEAR) |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
