Toyota Century
1982-10 → 1987-09 · chassis VG40 · catalogue 341120 · Japan
Discontinued model
Data version 1988-03
Front Seat & Seat Track
63 part groups · 6 illustrations
Part groups
| PNC | Description |
|---|---|
| 71071P | Cover, Front Seat Cushion(FOR SEMI-SEPARATE TYPE) |
| 71071S | Cover, Front Seat Cushion, RH(FOR SEPARATE TYPE) |
| 71072S | Cover, Front Seat Cushion, LH(FOR SEPARATE TYPE) |
| 71073P | Cover, Front Seatback, RH(FOR SEMI-SEPARATE TYPE) |
| 71073S | Cover, Front Seatback, RH(FOR SEPARATE TYPE) |
| 71074P | Cover, Front Seatback, LH(FOR SEMI-SEPARATE TYPE) |
| 71074S | Cover, Front Seatback, LH(FOR SEPARATE TYPE) |
| 71084S | Cover Sub-assy, Front Seatback, Inside LH |
| 71410P | Cushion Assy, Front Seat(FOR SEMI-SEPARATE TYPE) |
| 71410S | Cushion Assy, Front Seat, RH(FOR SEPARATE TYPE) |
| 71420S | Cushion Assy, Front Seat, LH (FOR SEPARATE TYPE) |
| 71430P | Back Assy, Front Seat, RH(FOR SEMI-SEPARATE TYPE) |
| 71430S | Back Assy, Front Seat, RH(FOR SEPARATE TYPE) |
| 71440P | Back Assy, Front Seat, LH(FOR SEMI-SEPARATE TYPE) |
| 71440S | Back Assy, Front Seat, LH(FOR SEPARATE TYPE) |
| 71553B | Pad, Front Seatback, B |
| 71705 | Board Sub-assy, Front Seatback, RH |
| 71705A | Clip(FOR FRONT SEATBACK BOARD) |
| 71706 | Board Sub-assy, Front Seatback, LH |
| 71770 | Pocket Sub-assy, Front Seatback |
| 71809B | Cover Sub-assy, Front Seat Armrest Holder |
| 71810 | Armrest Assy, Front Seat Center |
| 71810B | Clip (FOR FRONT SEAT CENTER ARMREST) |
| 71811D | Shield, Front Seat Cushion, RH |
| 71812A | Ring, Hog, Small (FOR FRONT SEAT) |
| 71812D | Shield, Front Seat Cushion, LH |
| 71821A | Clip (FOR FRONT SEAT SIDE SHIELD) |
| 71824 | Bracket, Front Seat Side, NO.1 RH |
| 71825 | Bracket, Front Seat Side, NO.1 LH |
| 71826 | Bracket, Front Seat Side, NO.2 |
| 71922A | Cover, Front Seat Headrest Under |
| 71950 | Headrest Assy, Front Seat |
| 71956A | Support, Front Seat Headrest |
| 71980 | Footrest Assy, Front Seat, NO.1 |
| 72110 | Regulator Assy, Power Seat, RH |
| 72120 | Track Assy, Front Seat, Outer LH |
| 72157 | Cover, Seat Track Bracket, Inner |
| 72310 | Cable Assy, Seat Adjust Drive, NO.1 |
| 72401 | Housing Sub-assy, Front Seat Motor Side |
| 72402 | Housing Sub-assy, Cable Side |
| 72405 | Housing Sub-assy, Front Seat Vertical |
| 72420 | Cable Assy, Seat Adjuster Drive, NO.2 |
| 72501C | Pipe Sub-assy, Reclining Connecting |
| 72510 | Adjuster Assy, Reclining Seatback, RH |
| 72510D | Adjuster Assy, Reclining Seat, Outer RH |
| 72520 | Adjuster Assy, Reclining Seatback, LH |
| 72520D | Adjuster Assy, Reclining Seat, Outer LH |
| 72524 | Handle, Reclining Adjuster Release |
| 72530A | Adjuster Assy, Reclining Seat, Inner RH |
| 72537 | Cover, Reclining Hinge Outer, RH |
| 72537B | Clip (FOR RECLINING HINGE OUTER COVER) |
| 72538 | Cover, Reclining Hinge Outer, LH |
| 72540A | Adjuster Assy, Reclining Seat, Inner LH |
| 72571A | Base, Reclining Control, RH |
| 72572A | Base, Reclining Control, LH |
| 72613 | Striker, Front Seatback Lock |
| 72805 | Link Sub-assy, Front Seat Center Armrest, RH |
| 72806 | Link Sub-assy, Front Seat Center Armrest, LH |
| 74630A | Grip Sub-assy, Assist, RH |
| 74640A | Grip Sub-assy, Assist, LH |
| 74808A | Box Sub-assy, Seat Trash |
| 74841A | Panel, Front Seatback Control |
| 74849A | Retainer, Front Seatback Control Panel Set |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
