Toyota Century

1982-10 → 1987-09 · chassis VG40 · catalogue 341120 · Japan

Discontinued model Data version 1988-03
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Armrest & Visor

28 part groups · 2 illustrations

Illustrations

Figure MBE268E MBE268E 1982-10 → — Figure MBE269D MBE269D 1982-10 → —

Part groups

PNCDescription
67651B Grille, Speaker Door, RH
67652B Grille, Speaker Door, LH
71788A Washer, Door Armrest Panel
74025 Cover Sub-assy, Front Door Armrest Upper, RH
74025A Hose, Front Door Courtesy Lamp
74026 Cover Sub-assy, Front Door Armrest Upper, LH
74027 Cover Sub-assy, Rear Door Armrest Upper, RH
74027A Hose, Rear Door Courtesy Lamp
74028 Cover Sub-assy, Rear Door Armrest Upper, LH
74031 Base Sub-assy, Front Door Armrest Lower, RH
74032 Base Sub-assy, Front Door Armrest Lower, LH
74033 Base Sub-assy, Rear Door Armrest Lower, RH
74034 Base Sub-assy, Rear Door Armrest Lower, LH
74210 Armrest Assy, Front, RH
74210H Plug, Hole (FOR DOOR ARMREST)
74220 Armrest Assy, Front, LH
74230 Armrest Assy, Rear, RH
74240 Armrest Assy, Rear, LH
74310 Visor Assy, RH
74320 Visor Assy, LH
74348 Holder, Visor
74603 Grip Sub-assy, Assist, Front
74604 Grip Sub-assy, Assist, Rear
74613 Plug, Assist Grip
74614 Spacer, Assist Grip
74631 Hook, Coat, A
74647 Base, Door Assist Grip
74671 Support, Assist Grip
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
