Toyota Century
1997-04 → 2017-01 · chassis GZG50 · catalogue 341140 · Japan
Discontinued model
Data version 2017-07
Rear Seat & Seat Track
86 part groups · 7 illustrations
Part groups
| PNC | Description |
|---|---|
| 71031S | Cover Sub-assy, Center Seat Cushion |
| 71075S | Cover, Rear Seat Cushion, RH (FOR SEPARATE TYPE) |
| 71076S | Cover, Rear Seat Cushion, LH (FOR SEPARATE TYPE) |
| 71077S | Cover, Rear Seatback, RH (FOR SEPARATE TYPE) |
| 71078S | Cover, Rear Seatback, LH(FOR SEPARATE TYPE) |
| 71206A | Bracket Sub-assy, Rear Seat Stopper, RH |
| 71207A | Bracket Sub-assy, Rear Seat Stopper, LH |
| 71281A | Hinge, Rear Seat Center Armrest |
| 71282A | Hinge, Rear Seat Center Armrest, LH |
| 71301S | Frame Sub-assy, Center Seat Cushion |
| 71310A | Cushion Assy, Center Seat |
| 71349B | Cover, Rear Seatback Stay, RH |
| 71369B | Cover, Rear Seatback Stay, LH |
| 71460S | Cushion Assy, Rear Seat, RH(FOR SEPARATE TYPE) |
| 71470S | Cushion Assy, Rear Seat, LH (FOR SEPARATE TYPE) |
| 71480S | Back Assy, Rear Seat, RH (FOR SEPARATE TYPE) |
| 71490S | Back Assy, Rear Seat, LH (FOR SEPARATE TYPE) |
| 71540A | Back Assy, Rear Side Seat, RH |
| 71550A | Back Assy, Rear Side Seat, LH |
| 71611A | Pad, Rear Seat Cushion, RH |
| 71612A | Pad, Rear Seat Cushion, LH |
| 71614 | Pad, Rear Seat Cushion, Center |
| 71628G | Spacer, Rear Seat Cushion, RH |
| 71628H | Spacer, Rear Seat Cushion, LH |
| 71650B | Spring Assy, Rear Seat Cushion, RH |
| 71651S | Pad, Rear Seatback, RH(FOR SEPARATE TYPE) |
| 71652C | Pad, Rear Seatback, B |
| 71652S | Pad, Rear Seatback, LH(FOR SEPARATE TYPE) |
| 71660B | Spring Assy, Rear Seat Cushion, LH |
| 71670S | Spring Assy, Rear Seatback, RH(FOR SEPARATE SEAT) |
| 71680S | Spring Assy, Rear Seatback, LH(FOR SEPARATE SEAT) |
| 71697 | Protector, Rear Seatback Edge |
| 71730A | Spring Assy, Rear Seatback, Lower RH |
| 71740A | Spring Assy, Rear Seatback, Lower LH |
| 71845A | Cover, Rear Seat Reclining, Upper RH |
| 71846A | Cover, Rear Seat Reclining, Upper LH |
| 71865 | Bezel, Rear Seat Cover, NO.1 |
| 71866A | Bezel, Rear Seat Cover, NO.2 |
| 71871A | Board, RR Seat Armrest Hole |
| 71931A | Support, Rear Seat Headrest |
| 71940A | Headrest Assy, Rear Seat |
| 71970B | Support Assy, Rear Seat Headrest, RH |
| 71990A | Support Assy, Rear Seat Headrest, LH |
| 72030 | Adjuster Assy, Rear NO.1 Seat |
| 72040 | Adjuster Assy, Rear NO.2 Seat |
| 72058A | Lever Sub-assy, Rear Seat Lock Control, LH |
| 72579A | Plate, Spring Set |
| 72693 | Hook, Rear Seat Cushion Lock |
| 72710B | Adjuster Assy, Rear Seatback, Inner RH |
| 72720B | Adjuster Assy, Rear Seatback, Inner LH |
| 72730E | Adjuster Assy, Rear Seatback, Outer RH |
| 72740E | Adjuster Assy, Rear Seatback, Outer LH |
| 72750G | Adjuster Assy, Lumbar Support, RH |
| 72760G | Adjuster Assy, Lumbar Support, LH |
| 72781B | Sprint, Rear Seat Plate |
| 72802A | Hinge Sub-assy, Armrest Console |
| 72808 | Link Sub-assy, Rear Seat Center Armrest, LH |
| 72809 | Lock Sub-assy, Center Armrest |
| 72830 | Armrest Assy, Rear Seat, Center |
| 72833A | Plate, Seat Center Armrest, Inner |
| 72834 | Panel, Rear Seat Center Armrest, NO.2 |
| 72836B | Arm, Rear Seat Armrest, LH |
| 72877B | Cover, Seat Armrest, RH |
| 72878B | Cover, Seat Armrest, LH |
| 72973J | Cover, Rear Seat Turn Table |
| 73705 | Bracket Sub-assy, Child Restraint Seat Anchor, RH |
| 73706 | Bracket Sub-assy, Child Restraint Seat Anchor, LH |
| 73930A | Airbag Assy, Rear Seat, RH |
| 73940A | Airbag Assy, Rear Seat, LH |
| 78980A | Footrest Assy, Rear Seat |
| 78987 | Cover, Rear Seat Footrest, NO.1 |
| 78988 | Stripe, Rear Door, Outside |
| 79014 | Cover Sub-assy, NO.1 Seatback, LH |
| 79150 | Back Assy, NO.1 Seat, LH |
| 85862A | Blower, Rear Seat Climate Control, RH |
| 85862B | Blower, Seat Climate Control, RH |
| 85863A | Blower, Seat Climate Control, LH |
| 85863B | Blower, Seat Climate Control, LH |
| 85864B | Controller, Seat Climate Control, RH |
| 85865B | Controller, Seat Climate Control, LH |
| 87202D | Duct, Heater Air, Rear |
| 87202E | Duct, Sub-assy Air, Rear, RH |
| 87203C | Duct, Sub-assy Air, Rear, LH |
| 88922A | Filter, Air |
| 88968 | Duct, Air Purifier, NO.1 |
| 88969 | Duct, Air Purifier, NO.2 |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
