Toyota Mark 2 V,WG

1988-10 → 1997-04 · chassis GX70,LX76,YX7# · catalogue 351110 · Japan

Discontinued model Data version 1997-10

Floor Pan & Lower Back Panel

37 part groups · 2 illustrations

PNC	Description
57207A	Bracket Sub-assy, Engine Rear Mounting Member, RH
57208B	Bracket Sub-assy, Engine Rear Mounting Member, LH
57408B	Member Sub-assy, Front Floor Cross
58111	Pan, Front Floor
58171	Reinforcement, Parking Brake Base
58173A	Deflector, Front Floor Stone, RH
58174	Deflector, Front Floor Stone, LH
58183	Bracket, Front Seat Mounting, Inner
58191	Footrest, Front Floor
58193	Bracket, Instrument Panel Brace Mounting
58208	Pan, Center Floor
58212C	Pan, Center Floor, Front
58233	Bracket, Exhaust Pipe Mounting
58235	Bracket, Differential Carrier Bumper Mounting
58261A	Cover, Transmission
58264B	Bracket, Parking Brake Cable Guide
58266B	Bracket, Fuel Tube Clamp
58286	Boot, Shift & Select Lever, NO.1
58288	Seal, Shift Lever Boot
58307	Panel Sub-assy, Body Lower Back
58311	Pan, Rear Floor
58313	Panel, Rear Floor Side, RH
58314	Panel, Rear Floor Side, LH
58318B	Reinforcement, Washer Tank Bracket
58319A	Plate, Rear Floor Panel, Front
58332A	Cover, Rear Floor Side Service Hole
58335A	Seal, Rear Floor Side Service Hole Cover
58336B	Reinforcement, Rear Floor Pan
58337B	Reinforcement, NO.7 Body Mounting
58338A	Reinforcement, Rear Floor Pan, NO.2
58346A	Bracket, Rear Floor Heat Insulator, NO.2
58389	Bracket, Rear Washer Tank Mounting, NO.2
58401D	Bracket Sub-assy, Rear Seat Support, NO.1
58460C	Striker Assy, Luggage Hold Belt
58709A	Carrier Sub-assy, Jack
59211	Deflector, Rear Bumper Stone
77029B	Cover Sub-assy, Fuel Sender Gage

PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
