Toyota Celsior
1994-10 → 2000-08 · chassis UCF2# · catalogue 431120 · Japan
Discontinued model
Data version 2001-03
Telephone & Mayday
28 part groups · 5 illustrations
Part groups
| PNC | Description |
|---|---|
| 82817R | Protector, Wiring Harness, NO.16 |
| 86011L | Filter, Noise |
| 86705 | Cord Sub-assy, Telephone Antenna |
| 86710 | Computer Assy, Telephone |
| 86712 | Wire, Telephone |
| 86714 | Controller, Telephone |
| 86719 | Bracket, Telephone |
| 86720A | Mobilephone Assy |
| 86722 | Cradle, Mobilephone |
| 86723 | Wire, Mobilephone |
| 86723A | Wire, Mobilephone |
| 86723B | Wire, Telephone Computer |
| 86724 | Guide, Curl Cord |
| 86725 | Battery, Mobilephone |
| 86726 | Cover, Mobilephone |
| 86726A | Cover, Mobilephone, NO.2 |
| 86726B | Cover, Mobilephone, NO.3 |
| 86726C | Cover, Mobilephone |
| 86729 | Bracket, Mobilephone |
| 86730 | Microphone Assy, Telephone |
| 86771B | Charger, Portablephone Battery |
| 86773 | Wire, Portablephone |
| 86774 | Charger, Portablephone AC |
| 86775A | Handset, Portablephone |
| 86776 | Battery, Portablephone-s |
| 86776A | Cover, Telephone Wire |
| 86777 | Battery, Mayday |
| 86779 | Strap, Portablephone |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
