Toyota Ipsum
1996-05 → 2001-05 · chassis CXM10,SXM1# · catalogue 511110 · Japan
Discontinued model
Data version 2002-01
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 82111 — Wire, Engine Room Main | ||||
| 82111-44010 |
Wire, Engine Room Main
1996-05 → 1997-08
ended
|
SXM1# E,IPSUM | ¥119,000 | |
| 82111-44020 |
Wire, Engine Room Main
1996-05 → 1997-08
ended
|
SXM1# L | ¥119,000 | |
| 82111-44020 note |
Wire, Engine Room Main
1996-05 → 1997-08
ended
|
SXM1# E,IPSUM | ¥119,000 | |
| 82111-44130 |
Wire, Engine Room Main
1997-09 → 1998-04
ended
|
CXM10 | ¥134,000 | |
| 82111-44200 |
Wire, Engine Room Main
1997-08 → 1998-04
ended
|
SXM1# E,IPSUM | ¥134,000 | |
| 82111-44210 |
Wire, Engine Room Main
1997-08 → 1998-04
ended
|
SXM1# ATG,L | ¥134,000 | |
| 82111-44210 note |
Wire, Engine Room Main
1997-08 → 1998-04
ended
|
SXM1# IPSUM | ¥134,000 | |
| 82111-44330 |
Wire, Engine Room Main
1998-04 → 2000-05
ended
|
SXM10 E,IPSUM | ¥148,000 | |
| 82111-44330 |
Wire, Engine Room Main
2000-05 → —
|
SXM10 ATG,E,IPSUM | ¥148,000 | |
| 82111-44340 note |
Wire, Engine Room Main
1998-04 → —
|
SXM10 ATG,IPSUM,L | ¥148,000 | |
| 82111-44340 note |
Wire, Engine Room Main
1998-06 → —
|
SXM10 IPSUM | ¥148,000 | |
| 82111-44350 |
Wire, Engine Room Main
1998-04 → —
|
SXM15 | ¥148,000 | |
| 82111-44430 |
Wire, Engine Room Main
1998-04 → —
|
CXM10 | ¥134,000 | |
| 82210C — Fusible Link | ||||
| 90982-08202 note |
Fusible Link
1996-05 → —
|
CXM10,SXM1# | ¥700 | |
| 90982-08254 note |
Fusible Link
1996-05 → —
|
CXM10,SXM1# | ¥440 | |
| 90982-08283 note |
Fusible Link
1996-05 → —
|
CXM10,SXM1# | ¥440 | |
| 90982-08284 note |
Fusible Link
1996-05 → —
|
CXM10,SXM1# | ¥590 | |
| 90982-08285 note |
Fusible Link
1996-05 → —
|
CXM10,SXM1# | ¥440 | |
| 82817 — Protector, Wiring Harness, NO.1 | ||||
| 82817-95702 |
Protector, Wiring Harness, NO.1
1996-05 → —
|
CXM10,SXM1# | ¥280 | |
| 82823 — Cap, Terminal, NO.1 | ||||
| 82823-22050 |
Cap, Terminal, NO.1
1996-05 → —
|
CXM10,SXM1# | ¥390 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
