Toyota Nadia
1998-07 → 2003-07 · chassis ACN1#,SXN1# · catalogue 512110 · Japan
Discontinued model
Data version 2004-01
Front Bumper & Bumper Stay
12 part groups · 5 illustrations
Part groups
| PNC | Description |
|---|---|
| 52115A | Support, Front Bumper Side, RH |
| 52116A | Support, Front Bumper Side, LH |
| 52119A | Cover, Front Bumper |
| 52127D | Cover, Front Bumper Hole, RH |
| 52128B | Cover, Front Bumper Hole, LH |
| 52143D | Bracket, Front Bumper Side, RH |
| 52144D | Bracket, Front Bumper Side, LH |
| 52145A | Stay, Front Bumper, NO.2 RH |
| 52146A | Stay, Front Bumper, NO.2 LH |
| 52161C | Piece, Front Bumper |
| 52535 | Retainer, Front Bumper Side, RH |
| 52536 | Retainer, Front Bumper Side, LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
