Toyota Gaia

1998-05 → 2004-09 · chassis ACM1#,CXM10,SXM1# · catalogue 513110 · Japan

Discontinued model Data version 2005-04
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Mudguard & Spoiler

30 part groups · 2 illustrations

Illustrations

Figure 760130F 760130F 1998-05 → — Figure 760190M 760190M 2000-04 → —

Part groups

PNCDescription
52161G Piece, Rear Bumper
52161H Piece, Rear Bumper
61786E Bracket, Rear Bumper Side, RH
61787D Bracket, Rear Bumper Side, LH
75861B Pad, Rocker Panel Moulding
76085 Spoiler Sub-assy, Rear
76851 Cover, Front Spoiler
76853A Retainer, Front Spoiler, Upper NO.1
76853D Retainer, Front Spoiler, NO.1
76854A Retainer, Front Spoiler, NO.2
76871 Spoiler, Rear
76872 Protector, Rear Spoiler, NO.1
76873 Protector, Rear Spoiler, NO.2
76873A Protector, Rear Spoiler, RH
76874 Protector, Rear Spoiler, NO.3
76874B Protector, Rear Spoiler, LH
76877D Protector, Front Spoiler Side, RH
76878A Protector, Front Spoiler Side, LH
76889 Clip, Rear Spoiler, NO.2
76901 Mudguard Sub-assy, Side, RH
76902 Mudguard Sub-assy, Side, LH
76905 Retainer Sub-assy, Side Mudguard, Lower RH
76906 Retainer Sub-assy, Side Mudguard, Lower LH
76921B Protector, Side Mudguard, NO.1
76922D Protector, Side Mudguard, NO.2
76923 Retainer, Side Mudguard
76925D Protector, Side Mudguard, RH
76933A Bracket, Side Mudguard, NO.2 RH
76934A Bracket, Side Mudguard, NO.2 LH
76935 Retainer, Side Mudguard, NO.7
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
