Toyota Isis
2004-09 → 2018-01 · chassis ANM1#,ZGM1#,ZNM10 · catalogue 513120 · Japan
Supported model
Data version 2018-07
Caution Plate (EXTERIOR & INTERIOR)
31 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 11285F | Label, Coolant System Caution |
| 11289B | Label, Spark Plug Notice |
| 11296C | Label, Engine Service Information |
| 16448A | Plate, Radiator Caution |
| 16793E | Label, Cooling Fan Caution |
| 41992 | Label, Differential Notice |
| 46275A | Label, Parking Brake Release Information, NO.1 |
| 46275B | Label, Parking Brake Release Information, NO.2 |
| 69339C | Label, Child Protector Information |
| 74511F | Label, Name (IDENTIFICATION LASER LABEL) |
| 74528F | Label, Door Closer Caution, RH |
| 74528G | Label, Power Slide Door Caution |
| 74528H | Label, Power Slide Door Caution |
| 74529B | Label, Back Door Open Stop Information |
| 74541E | Plate, Compact Spare Tire Caution |
| 74541H | Plate, Body Caution |
| 74544D | Plate, Tire Carrier Caution |
| 74548 | Plate, Body Caution |
| 74551C | Plate, Rear Seat Protector Caution |
| 74552A | Label, Safety Caution |
| 74553A | Plate, Front Seat Caution |
| 74553F | Label, Front Seat Caution |
| 74554 | Plate, Seatback Stopper Caution, LH |
| 74561A | Label, Fuel Consumption Information |
| 74562B | Label, Emission Information |
| 74598A | Label, Passenger Airbag Caution |
| 74751 | Label, Tire Pressure Information |
| 85628C | Label, Automatic Door |
| 87529B | Label, A/C Filter Information |
| 88723E | Label, Cooler Service Caution |
| 89176A | Label, Airbag Deployment Information |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
