Toyota Isis
2004-09 → 2018-01 · chassis ANM1#,ZGM1#,ZNM10 · catalogue 513120 · Japan
Supported model
Data version 2018-07
Heating & Air Conditioning - Control & Air Duct
29 part groups · 5 illustrations
Part groups
| PNC | Description |
|---|---|
| 55244C | Silencer, Front Panel Side, NO.2 LH |
| 55843A | Duct, Heater TO Register, NO.1 |
| 55843B | Clip, Heater TO Register Duct |
| 55844 | Duct, Heater TO Register, NO.2 |
| 55846D | Clip, Heater TO Register Duct |
| 55900 | Control Assy, Air Conditioner |
| 55900B | Bulb, Air Conditioner Control |
| 55904A | Housing Sub-assy, Heater Control |
| 55936B | Switch, Center Cluster Module |
| 55950G | Nozzle Assy, Defroster |
| 55971C | Duct, Side Defroster Nozzle, NO.1 |
| 55972C | Duct, Side Defroster Nozzle, NO.2 |
| 84331A | Knob, Hazard Warning Signal Switch |
| 87201 | Duct Sub-assy, Air, NO.1 |
| 87201K | Clip (FOR AIR DUCT) |
| 87211A | Duct, Air, NO.2 |
| 87212 | Duct, Air, Rear NO.1 |
| 87213 | Duct, Air, Rear NO.2 |
| 87213A | Duct, Air Rear NO.2 |
| 87214D | Duct, Air, Rear NO.3 |
| 87214M | Duct, Heater TO Foot, NO.3 |
| 87215F | Duct, Air, Rear NO.3 |
| 87215J | Clip (FOR AIR REAR DUCT) |
| 87216B | Duct, Air, Rear NO.4 |
| 87275 | Duct, Floor Heater Air, NO.1 RH |
| 88625H | Thermistor, Cooler (SOLAR SENSOR) |
| 88625P | Thermistor, Cooler (AMBIENT TEMP. SENSOR) |
| 88625Q | Thermistor, Cooler (ROOM TEMP. SENSOR) |
| 88650B | Amplifier Assy, Airconditioner |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
