Toyota Harrier
1997-12 → 2003-02 · chassis ACU1#,MCU1#,SXU1# · catalogue 521110 · Japan
Discontinued model
Data version 2004-01
Back Door Panel & Glass
16 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 64276A | Bracket, Back Panel Trim, Upper |
| 64780A | Panel Assy, Back Door Trim |
| 64783A | Trim, Back Window Panel, Upper |
| 64790B | Panel Assy, Back Door Trim, Upper |
| 64791C | Cover, Back Door Trim, RH |
| 64792 | Cover, Back Door Trim, LH |
| 64818B | Spacer, Back Door Glass, NO.1 |
| 64819 | Spacer, Back Window Glass, NO.2 |
| 67005 | Panel Sub-assy, Back Door |
| 67281B | Stopper, Back Door, Lower |
| 67293 | Cushion, Back Door Lower Stopper |
| 67881A | Weatherstrip, Back Door |
| 68131 | Glass, Back Door |
| 74811D | Handle, Door Pull |
| 75129C | Cushion, Rear Licence Plate |
| 75573C | Moulding, Back Window, Outside |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
