Toyota Harrier

2003-02 → 2012-07 · chassis ACU3#,GSU3#,MCU3# · catalogue 521120 · Japan

Supported model Data version 2012-07
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Caution Plate (EXTERIOR & INTERIOR)

24 part groups · 4 illustrations

Illustrations

Figure 745941A 745941A 2003-02 → — Figure 741208M 741208M 2003-02 → — Figure 741779F 741779F 2003-02 → — Figure 741808E 741808E 2003-02 → —

Part groups

PNCDescription
11296C Label, Engine Service Information
16448A Plate, Radiator Caution
16793E Label, Cooling Fan Caution
17791A Label, Maintenance Information
41992 Label, Differential Notice
46275A Label, Parking Brake Release Information, NO.1
46275B Label, Parking Brake Release Information, NO.2
48969 Label, Jack UP Caution
58879D Label, Console Door Lock Caution
69339C Label, Child Protector Information
74511F Label, Name (IDENTIFICATION LASER LABEL)
74515A Plate, Theft Warning
74528J Label, Power Back Door Caution
74541B Plate, Compact Spare Tire Caution
74544D Plate, Tire Carrier Caution
74561A Label, Fuel Consumption Information
74562B Label, Emission Information
74579A Label, Unleaded Fuel Information
74598A Label, Passenger Airbag Caution
74751 Label, Tire Pressure Information
87529B Label, A/C Filter Information
88723E Label, Cooler Service Caution
88723H Label, Cooler Service Caution
89176A Label, Airbag Deployment Information
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
