Toyota Harrier HV

2005-03 → 2012-06 · chassis MHU38 · catalogue 524110 · Japan

Supported model Data version 2013-01
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Reflex Reflector

7 part groups · 2 illustrations

Illustrations

Figure 813225A 813225A 2005-03 → — Figure 813226A 813226A 2005-03 → —

Part groups

PNCDescription
81910 Reflector Assy, Reflex, RH
81910B Bulb, Reflex Reflector
81910I Socket Plug, Reflex Reflector,RH
81911 Lens, Reflex Reflector, Rear RH
81920 Reflector Assy, Reflex, LH
81920C Socket Plug, Reflex Reflector LH
81921 Lens, Reflex Reflector, Rear LH
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
