Toyota Lexus UX Series
2022-07 → present · chassis MZAA10,MZAH1#,KMA10 · catalogue 537120 · Japan
Supported model
Data version 2024-01
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 82210N — Instrument Panel Fusible Link | ||||
| 90982-08306 note |
Instrument Panel Fusible Link
2022-07 → —
|
MZAA10,MZAH10,15 | ¥390 | |
| 90982-08306 note |
Instrument Panel Fusible Link
2022-07 → 2024-01
ended
|
KMA10 | ¥390 | |
| 90982-08306 note |
Instrument Panel Fusible Link
2024-01 → —
|
KMA10,MZAH11,16 | ¥390 | |
| 82600D — Instrument Panel Fuse | ||||
| 90982-09019 note |
Instrument Panel Fuse
2022-07 → 2024-01
ended
|
KMA10 | ¥70 | |
| 90982-09019 note |
Instrument Panel Fuse
2022-07 → —
|
MZAA10,MZAH10,15 | ¥70 | |
| 90982-09020 note |
Instrument Panel Fuse
2022-07 → 2024-01
ended
|
KMA10 | ¥70 | |
| 90982-09020 note |
Instrument Panel Fuse
2022-07 → —
|
MZAA10,MZAH10,15 | ¥70 | |
| 90982-09021 note |
Instrument Panel Fuse
2022-07 → —
|
MZAA10,MZAH10,15 | ¥70 | |
| 90982-09021 note |
Instrument Panel Fuse
2022-07 → 2024-01
ended
|
KMA10 | ¥70 | |
| 90982-09022 note |
Instrument Panel Fuse
2022-07 → 2024-01
ended
|
KMA10 | ¥70 | |
| 90982-09022 note |
Instrument Panel Fuse
2022-07 → —
|
MZAA10,MZAH10,15 | ¥70 | |
| 90982-09023 note |
Instrument Panel Fuse
2022-07 → 2024-01
ended
|
KMA10 | ¥70 | |
| 90982-09023 note |
Instrument Panel Fuse
2022-07 → —
|
MZAA10,MZAH10,15 | ¥70 | |
| 90982-09019 note |
Instrument Panel Fuse
2024-01 → —
|
KMA10,MZAH11,16 | ¥70 | |
| 90982-09020 note |
Instrument Panel Fuse
2024-01 → —
|
KMA10,MZAH11,16 | ¥70 | |
| 90982-09021 note |
Instrument Panel Fuse
2024-01 → —
|
KMA10,MZAH11,16 | ¥70 | |
| 90982-09022 note |
Instrument Panel Fuse
2024-01 → —
|
KMA10,MZAH11,16 | ¥70 | |
| 90982-09023 note |
Instrument Panel Fuse
2024-01 → —
|
KMA10,MZAH11,16 | ¥70 | |
| 90982-09025 note |
Instrument Panel Fuse
2024-01 → —
|
KMA10,MZAH11,16 | ¥80 | |
| 82663B — Cover, Relay Block, Lower, NO.3 | ||||
| 82663-76020 |
Cover, Relay Block, Lower, NO.3
2022-07 → 2024-01
ended
|
KMA10 | ¥400 | |
| 82663-76020 |
Cover, Relay Block, Lower, NO.3
2022-07 → —
|
MZAA10,MZAH10,15 | ¥400 | |
| 82663-76020 |
Cover, Relay Block, Lower, NO.3
2024-01 → —
|
KMA10,MZAH11,16 | ¥400 | |
| 82663D — Cover, Relay Block, Lower, NO.5 | ||||
| 82663-76050 |
Cover, Relay Block, Lower, NO.5
2022-07 → 2024-01
ended
|
KMA10 | ¥400 | |
| 82663-76050 |
Cover, Relay Block, Lower, NO.5
2022-07 → —
|
MZAA10,MZAH10,15 | ¥400 | |
| 82663-76050 |
Cover, Relay Block, Lower, NO.5
2024-01 → —
|
KMA10,MZAH11,16 | ¥400 | |
| 82666J — Holder, Connector, NO.3 | ||||
| 82666-76230 |
Holder, Connector, NO.3
2022-07 → —
|
MZAA10,MZAH10,15 | ¥1,110 | |
| 82666-76230 |
Holder, Connector, NO.3
2022-07 → 2024-01
ended
|
KMA10 | ¥1,110 | |
| 82666-76230 |
Holder, Connector, NO.3
2024-01 → —
|
KMA10,MZAH11,16 | ¥1,110 | |
| 82672K — Cover, Power Distribution Box | ||||
| 82672-76050 |
Cover, Power Distribution Box
2024-01 → —
|
KMA10,MZAH11,16 | ¥260 | |
| 82673A — Bracket, Junction Block, NO.1 | ||||
| 82673-47190 |
Bracket, Junction Block, NO.1
2022-07 → 2024-01
ended
|
KMA10 | ¥550 | |
| 82673-47190 |
Bracket, Junction Block, NO.1
2022-07 → —
|
MZAA10,MZAH10,15 | ¥550 | |
| 82673-16050 |
Bracket, Junction Block, NO.1
2024-01 → —
|
KMA10,MZAH11,16 | — | |
| 82673B — Bracket, Junction Block, NO.2 | ||||
| 82673-47210 |
Bracket, Junction Block, NO.2
2022-07 → 2024-01
ended
|
KMA10 | ¥750 | |
| 82673-47210 |
Bracket, Junction Block, NO.2
2022-07 → —
|
MZAA10,MZAH10,15 | ¥750 | |
| 82673-16060 |
Bracket, Junction Block, NO.2
2024-01 → —
|
KMA10,MZAH11,16 | — | |
| 82730G — Box Assy, Power Distribution | ||||
| 82730-76060 |
Box Assy, Power Distribution
2024-01 → —
|
KMA10,MZAH11,16 | ¥19,400 | |
| 82878 — Box, Computer Integration, LH | ||||
| 82878-47020 |
Box, Computer Integration, LH
2022-07 → 2024-01
ended
|
KMA10 | ¥2,780 | |
| 82878-47020 |
Box, Computer Integration, LH
2022-07 → —
|
MZAA10,MZAH10,15 | ¥2,780 | |
| 82878-16010 |
Box, Computer Integration, LH
2024-01 → 2025-12
ended
|
KMA10 | ¥3,000 | |
| 82878-16010 |
Box, Computer Integration, LH
2024-01 → —
|
MZAH11,16 | ¥3,000 | |
| 83650 — Fusee | ||||
| 90986-01005 |
Fusee
2022-07 → 2024-01
ended
|
KMA10 | — | |
| 90986-01005 |
Fusee
2022-07 → —
|
MZAA10,MZAH10,15 | — | |
| 90986-01005 |
Fusee
2024-01 → 2025-12
ended
|
KMA10 | — | |
| 90986-01005 |
Fusee
2024-01 → —
|
MZAH11,16 | — | |
| 83651 — Clamp, Fusee | ||||
| 62199-48010 |
Clamp, Fusee
2022-07 → 2024-01
ended
|
KMA10 | ¥130 | |
| 62199-48010 |
Clamp, Fusee
2022-07 → —
|
MZAA10,MZAH10,15 | ¥130 | |
| 62199-48010 |
Clamp, Fusee
2024-01 → 2025-12
ended
|
KMA10 | ¥130 | |
| 62199-48010 |
Clamp, Fusee
2024-01 → —
|
MZAH11,16 | ¥130 | |
| 84340 — Switch Assy, Stop Lamp | ||||
| 84340-19095 |
Switch Assy, Stop Lamp
2022-07 → 2024-01
ended
|
KMA10 | ¥1,620 | |
| 84340-19095 |
Switch Assy, Stop Lamp
2022-07 → —
|
MZAA10,MZAH10,15 | ¥1,620 | |
| 84340-19095 |
Switch Assy, Stop Lamp
2024-01 → 2025-12
ended
|
KMA10 | ¥1,620 | |
| 84340-19095 |
Switch Assy, Stop Lamp
2024-01 → —
|
MZAH11,16 | ¥1,620 | |
| 84345 — Adjuster, Stop Lamp Switch Mounting | ||||
| 84345-51010 |
Adjuster, Stop Lamp Switch Mounting
2022-07 → 2024-01
ended
|
KMA10 | ¥220 | |
| 84345-51010 |
Adjuster, Stop Lamp Switch Mounting
2022-07 → —
|
MZAA10,MZAH10,15 | ¥220 | |
| 84345-51010 |
Adjuster, Stop Lamp Switch Mounting
2024-01 → 2025-12
ended
|
KMA10 | ¥220 | |
| 84345-51010 |
Adjuster, Stop Lamp Switch Mounting
2024-01 → —
|
MZAH11,16 | ¥220 | |
| 85930G — Relay, Acc | ||||
| 90987-02027 |
Relay, Acc
2022-07 → —
|
MZAA10,MZAH10,15 | ¥2,930 | |
| 90987-02027 note |
Relay, Acc
2022-07 → —
|
MZAH10,15 | ¥2,930 | |
| 90987-02027 |
Relay, Acc
2023-04 → 2024-01
ended
|
KMA10 | ¥2,930 | |
| 90987-02027 |
Relay, Acc
2024-01 → 2025-12
ended
|
KMA10 | ¥2,930 | |
| 90987-02027 |
Relay, Acc
2024-01 → —
|
MZAH11,16 | ¥2,930 | |
| 85940 — Relay Assy, Windshield Wiper | ||||
| 85940-76030 |
Relay Assy, Windshield Wiper
2022-07 → 2024-01
ended
|
KMA10 | ¥5,700 | |
| 85940-76030 |
Relay Assy, Windshield Wiper
2022-07 → —
|
MZAA10,MZAH10,15 | ¥5,700 | |
| 85940-76030 |
Relay Assy, Windshield Wiper
2024-01 → 2025-12
ended
|
KMA10 | ¥5,700 | |
| 85940-76030 |
Relay Assy, Windshield Wiper
2024-01 → —
|
MZAH11,16 | ¥5,700 | |
| 867N0A — Relay, Drive Recorder | ||||
| 90987-04004 note |
Relay, Drive Recorder
2024-01 → 2025-12
ended
|
KMA10 | ¥2,810 | |
| 90987-04004 note |
Relay, Drive Recorder
2024-01 → —
|
MZAH11,16 | ¥2,810 | |
| 869A1 — Computer, Intelligent Transport Systems Communication | ||||
| 869A0-76010 note |
Computer, Intelligent Transport Systems Communication
2022-07 → —
|
MZAH10,15 | ¥49,500 | |
| 869A0-76020 note |
Computer, Intelligent Transport Systems Communication
2022-07 → —
|
MZAA10 | ¥49,500 | |
| 869A0-76030 note |
Computer, Intelligent Transport Systems Communication
2023-04 → 2024-01
ended
|
KMA10 | ¥68,200 | |
| 869A0-76050 note |
Computer, Intelligent Transport Systems Communication
2024-01 → 2025-12
ended
|
KMA10 | ¥61,900 | |
| 869A0-76050 note |
Computer, Intelligent Transport Systems Communication
2024-01 → —
|
MZAH11,16 | ¥61,900 | |
| 89111 — Computer, Network Gateway | ||||
| 89111-76070 |
Computer, Network Gateway
2022-07 → —
|
MZAH10,15 | ¥5,500 | |
| 89111-76080 |
Computer, Network Gateway
2023-04 → 2024-01
ended
|
KMA10 | ¥6,200 | |
| 89111-76090 |
Computer, Network Gateway
2022-07 → —
|
MZAA10 | ¥5,500 | |
| 89111-76120 |
Computer, Network Gateway
2024-01 → 2025-12
ended
|
KMA10 | ¥5,500 | |
| 89111-76130 |
Computer, Network Gateway
2024-01 → 2025-11
ended
|
MZAH11,16 | ¥5,500 | |
| 89120A — Sensor, Automatic Light Control | ||||
| 89121-30020 |
Sensor, Automatic Light Control
2022-07 → 2024-01
ended
|
KMA10 | ¥4,010 | |
| 89121-30020 |
Sensor, Automatic Light Control
2022-07 → —
|
MZAA10,MZAH10,15 | ¥4,010 | |
| 89121-30020 |
Sensor, Automatic Light Control
2024-01 → —
|
MZAH11,16 | ¥4,010 | |
| 89121-30020 |
Sensor, Automatic Light Control
2024-01 → 2025-12
ended
|
KMA10 | ¥4,010 | |
| 89221 — Computer, Multiplex Network Body | ||||
| 892H0-76N70 |
Computer, Multiplex Network Body
2022-07 → —
|
MZAA10,MZAH10,15 | ¥34,400 | |
| 892H0-76Y70 |
Computer, Multiplex Network Body
2023-04 → 2024-01
ended
|
KMA10 | ¥34,400 | |
| 892H0-76390 |
Computer, Multiplex Network Body
2024-01 → 2025-12
ended
|
KMA10,MZAH11,16 | ¥31,300 | |
| 89227 — Computer, Multiplex Tilt & Telescopic | ||||
| 89227-76020 |
Computer, Multiplex Tilt & Telescopic
2022-07 → 2024-01
ended
|
KMA10 | ¥19,400 | |
| 89227-76020 |
Computer, Multiplex Tilt & Telescopic
2022-07 → —
|
MZAA10,MZAH10,15 | ¥19,400 | |
| 89227-76030 |
Computer, Multiplex Tilt & Telescopic
2024-01 → 2025-12
ended
|
KMA10 | ¥21,900 | |
| 89227-76030 |
Computer, Multiplex Tilt & Telescopic
2024-01 → —
|
MZAH11,16 | ¥21,900 | |
| 895A0A — Computer Assy, Stop Lamp Control | ||||
| 895A0-30010 |
Computer Assy, Stop Lamp Control
2022-07 → 2024-01
ended
|
KMA10 | ¥3,720 | |
| 895A0-30010 |
Computer Assy, Stop Lamp Control
2022-07 → —
|
MZAA10,MZAH10,15 | ¥3,720 | |
| 895A0-30010 |
Computer Assy, Stop Lamp Control
2024-01 → 2025-12
ended
|
KMA10 | ¥3,720 | |
| 895A0-30010 |
Computer Assy, Stop Lamp Control
2024-01 → —
|
MZAH11,16 | ¥3,720 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
