Toyota Lexus UX300E

2021-02 → 2022-11 · chassis KMA10 · catalogue 538110 · Japan

Supported model Data version 2022-11
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Roof Headlining & Silencer Pad

8 part groups · 2 illustrations

Illustrations

Figure 644858A 644858A 2021-02 → — Figure 644857A 644857A 2021-02 → —

Part groups

PNCDescription
63306 Trim Sub-assy, Sunshade
63310 Headlining Assy, Roof
63310D Clip, Roof Headlining
63339A Cover, Roof Headlining Service Hole
63341 Pad, Roof Silencer, NO.1
63345 Pad, Roof Silencer, NO.5
63346 Pad, Roof Silencer, NO.6
63357B Silencer, Roof
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
