Toyota Yaris Cross
2020-08 → present · chassis MXPB1#,MXPJ1# · catalogue 541110 · Japan
Supported model
Data version 2024-01
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 42311U — Bolt, Hub(FOR REAR AXLE RH) | ||||
| 90942-02049 |
Bolt, Hub(FOR REAR AXLE RH)
2020-08 → 2024-01
ended
|
MXPB1#,MXPJ1# | ¥240 | |
| 90942-02049 |
Bolt, Hub(FOR REAR AXLE RH)
2024-01 → —
|
MXPB1#,MXPJ1# | ¥240 | |
| 42312E — Bolt, Hub(FOR REAR AXLE LH) | ||||
| 90942-02049 |
Bolt, Hub(FOR REAR AXLE LH)
2020-08 → 2024-01
ended
|
MXPB1#,MXPJ1# | ¥240 | |
| 90942-02049 |
Bolt, Hub(FOR REAR AXLE LH)
2024-01 → —
|
MXPB1#,MXPJ1# | ¥240 | |
| 42421E — Bolt (FOR REAR AXLE BEARING CASE RH) | ||||
| 90105-12408 |
Bolt (FOR REAR AXLE BEARING CASE RH)
2020-08 → 2024-01
ended
|
MXPB1#,MXPJ1# G,HBDG,HBDX,HBDZ,X,Z | ¥190 | |
| 90119-12488 |
Bolt (FOR REAR AXLE BEARING CASE RH)
2022-08 → 2024-01
ended
|
MXPB10,MXPJ10 GRS | ¥190 | |
| 90105-12408 |
Bolt (FOR REAR AXLE BEARING CASE RH)
2024-01 → —
|
MXPB1#,MXPJ1# G,HBDG,HBDX,HBDZ,U,X,Z | ¥190 | |
| 90119-12488 |
Bolt (FOR REAR AXLE BEARING CASE RH)
2024-01 → —
|
MXPB10,MXPJ10 GRS | ¥190 | |
| 42422A — Bolt (FOR REAR AXLE BEARING CASE LH) | ||||
| 90105-12408 |
Bolt (FOR REAR AXLE BEARING CASE LH)
2020-08 → 2024-01
ended
|
MXPB1#,MXPJ1# G,HBDG,HBDX,HBDZ,X,Z | ¥190 | |
| 90119-12488 |
Bolt (FOR REAR AXLE BEARING CASE LH)
2022-08 → 2024-01
ended
|
MXPB10,MXPJ10 GRS | ¥190 | |
| 90105-12408 |
Bolt (FOR REAR AXLE BEARING CASE LH)
2024-01 → —
|
MXPB1#,MXPJ1# G,HBDG,HBDX,HBDZ,U,X,Z | ¥190 | |
| 90119-12488 |
Bolt (FOR REAR AXLE BEARING CASE LH)
2024-01 → —
|
MXPB10,MXPJ10 GRS | ¥190 | |
| 42431 — Disc, Rear | ||||
| 42431-52180 |
Disc, Rear
2020-08 → 2024-01
ended
|
MXPB10,MXPJ10 | ¥6,100 | |
| 42431-78010 |
Disc, Rear
2020-08 → 2024-01
ended
|
MXPB15,MXPJ15 | ¥6,600 | |
| 42431-52180 |
Disc, Rear
2024-01 → —
|
MXPB10,MXPJ10 | ¥6,100 | |
| 42431-78010 |
Disc, Rear
2024-01 → —
|
MXPB15,MXPJ15 | ¥6,600 | |
| 42450A — Hub & Bearing Assy, Rear Axle, RH | ||||
| 42410-10020 |
Hub & Bearing Assy, Rear Axle, RH
2020-08 → 2024-01
ended
|
MXPB15,MXPJ15 | ¥16,200 | |
| 42450-52140 |
Hub & Bearing Assy, Rear Axle, RH
2020-08 → 2024-01
ended
|
MXPB10,MXPJ10 | ¥22,600 | |
| 42410-10020 |
Hub & Bearing Assy, Rear Axle, RH
2024-01 → —
|
MXPB15,MXPJ15 | ¥16,200 | |
| 42450-52140 |
Hub & Bearing Assy, Rear Axle, RH
2024-01 → —
|
MXPB10,MXPJ10 | ¥22,600 | |
| 42450B — Hub & Bearing Assy, Rear Axle, LH | ||||
| 42410-10020 |
Hub & Bearing Assy, Rear Axle, LH
2020-08 → 2024-01
ended
|
MXPB15,MXPJ15 | ¥16,200 | |
| 42450-52140 |
Hub & Bearing Assy, Rear Axle, LH
2020-08 → 2024-01
ended
|
MXPB10,MXPJ10 | ¥22,600 | |
| 42410-10020 |
Hub & Bearing Assy, Rear Axle, LH
2024-01 → —
|
MXPB15,MXPJ15 | ¥16,200 | |
| 42450-52140 |
Hub & Bearing Assy, Rear Axle, LH
2024-01 → —
|
MXPB10,MXPJ10 | ¥22,600 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
