Toyota Yaris Cross
2020-08 → present · chassis MXPB1#,MXPJ1# · catalogue 541110 · Japan
Supported model
Data version 2024-01
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 83107A — Bracket Sub-assy, Meter, NO.1 | ||||
| 83107-K0021 note |
Bracket Sub-assy, Meter, NO.1
2020-08 → 2024-01
ended
|
MXPB1#,MXPJ1# HBDZ,Z | ¥2,340 | |
| 83107-K0021 note |
Bracket Sub-assy, Meter, NO.1
2024-01 → —
|
MXPB1#,MXPJ1# HBDZ,Z | ¥2,340 | |
| 83108 — Mirror Sub-assy, Meter | ||||
| 83108-52010 note |
Mirror Sub-assy, Meter
2020-08 → 2024-01
ended
|
MXPB1#,MXPJ1# HBDZ,Z | ¥55,100 | |
| 83108-52070 note |
Mirror Sub-assy, Meter
2024-01 → 2024-11
ended
|
MXPB1#,MXPJ1# HBDZ,Z | ¥67,100 | |
| 83108-52071 note |
Mirror Sub-assy, Meter
2024-12 → —
|
MXPB1#,MXPJ1# HBDZ,Z | ¥61,000 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
